STEP-UP, 600 kHz, PWM CONTROL OR PWM/PFM SWITCHABLE SWITCHING REGULATOR CONTROLLER
S-8340/8341 Series
Rev.4.0_00
Seiko Instruments Inc.
36
Performance Data for Parts
The following shows the performance of external parts.
Table 16 Performance of External Parts
Component
Product Name
Manufacturer
Performance
L
DC resistance
Max. Current
Diameter
Height
Inductor
CDRH5D18
Sumida
Corporation
4.1
μH
0.042
Ω typ.
0.057
Ω max.
1.95 A
5.7 mm
typ.
6.0 mm
max.
1.8 mm
typ.
2.0 mm
max.
CDRH124
10
μH
0.028
Ω max.
4.5 A
12.0 mm
typ.
12.3 mm
max.
4.5 mm
max.
CDRH6D28
10
μH
0.048
Ω typ.
0.065
Ω max.
1.70 A
6.7 mm
typ.
7.0 mm
max.
3.0 mm
max.
RB491D
Forward current 1.0 A @VF = 0.45 V, Vrm = 25 V
Diode
RB081L
20
Rohm
Corporation
Forward current 5.0 A @VF = 0.45 V, Vrm = 25 V
F951C476MG1
47
μF, 16 V, 5.5 × 4.8 × 2.3 mm max.,
ESR = 0.08
Ω (nominal value)
F951A476MF1
47
μF, 10 V, 5.5 × 4.8 × 2.0 mm max.,
ESR = 0.1
Ω (nominal value)
F920J476MB3
47
μF, 6.3 V, 3.6 × 3 × 1.2 mm max.,
ESR = 0.27
Ω (nominal value)
Capacitor
(output
capacitance)
(tantalum
electrolytic
capacitor)
F951A107MG1
Nichicon
Corporation
100
μF, 10 V, 5.5 × 4.8 × 2.3 mm max.,
ESR = 0.08
Ω (nominal value)
NDS335N
*1
VDSS = 20 V max., VGSS = 8 V max., ID = 1.7 A max.,
Vth = 0.5 V to 1 V, Ciss = 240 pF typ.,
RDS(ON) = 0.14 Ω max.(VGS = 2.7 V), SOT-23-3 package or
equivalent
External
transistor
(N-channel
FET)
FDN335N
Fairchild
Semiconductor
Corporation
VDSS = 20 V max., VGSS = 8 V max., ID = 1.7 A max.,
Vth = 0.4 V to 1.5 V, Ciss = 310 pF typ.,
RDS(ON) = 0.10 Ω max.(VGS = 2.5 V), SOT-23-3 package or
equivalent
FTS2001
Sanyo Electric
Co., Ltd.
VDSS = 20 V max., VGSS = 8 V max., ID = 5 A max.,
Vth = 0.4 V to 1.3 V, Ciss = 750 pF typ.,
RDS(ON) = 0.046 Ω max.(VGS = 2.5 V), 8-Pin TSSOP package
*1. The manufacturer recommends the FDN335N as an alternative for the NDS335N.
Caution
The value of each characteristic in Table 16 depends on the materials prepared by each manufacturer,
however, confirm the specifications by referring to respective materials when using any of the above.
