Rev.3.1_00
ULTRA-SMALL PACKAGE HIGH-PRECISION
VOLTAGE DETECTOR
S-808xxC Series
Seiko Instruments Inc.
1
The S-808xxC series is a series of high-precision
voltage detectors developed using CMOS process. The
detection voltage is fixed internally with an accuracy of
±2.0%. Two output forms, Nch open-drain and CMOS
output, are available. Ultra-low current consumption and
miniature package lineup can meet demand from the
portable device applications.
Features
Ultra-low current consumption
1.3
A typ. (detection voltage≤1.4 V, at VDD=1.5 V)
0.8
A typ. (detection voltage≥1.5 V, at VDD=3.5 V)
High-precision detection voltage ±2.0 %
Operating voltage range
0.65 V to 5.0 V (detection voltage
≤1.4 V)
0.95 V to 10.0 V (detection voltage
≥1.5 V)
Hysteresis characteristics
5 % typ.
Detection voltage
0.8 V to 6.0 V (0.1 V step)
Output form
Nch open-drain output (Active Low)
CMOS output (Active Low)
Applications
Battery checkers
Power failure detectors
Power monitor for portable equipments such as pagers, calculators, electronic notebooks and remote
controllers.
Constant voltage power monitor for cameras, video equipments and communication devices.
Power monitor for microcomputers and reset for CPUs.
Packages
Package name
Drawing code
Package
Tape
Reel
Zigzag
SC-82AB
NP004-A
SOT-23-5
MP005-A
SOT-89-3
UP003-A
SNT-4A
PF004-A
TO-92 (Bulk)
YS003-B
TO-92 (Tape and reel)
YF003-A
TO-92 (Tape and ammo)
YF003-A
YZ003-C
YZ003-C
