RM0552
Pending Obsolescence
Contact Product Information Center
Industrial Panel Mount Switches and Lights
AlwaysEU RoHS/ELV Compliant
(
Statement ofCompliance
)
Product Highlights:
Switch
Switch Type = Pushbutton
Operating Function = Momentary
Contact Rating = 6A
Reliant'22 Series
View all Features
|
FindSimilar Products
Previous
1
...
6
7
8
9
[10]
...
20
Next
QuickLinks
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Compare Products
Contact Us About This Product
Documentation& Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
ALCOSWITCH PRODUCTS
(PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
List all Documents
Additional Information:
Product Line Information
RelatedProducts:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Switch
Actuator Style = Mushroom
FrameStyle = Front Beveled
Comment = Contact Blocks Not Supplied, Order Separately
Mechanical Attachment:
Panel Cutout = 22mm Diameter
Electrical Characteristics:
Contact Rating = 6A
Oil-Tight = Yes
TerminationRelated Features:
Seal Type = IP65
Body RelatedFeatures:
Switch Type = Pushbutton
Series = Reliant'22
Actuator Profile = Extended
Actuator Color = Red
Bushing Material = Heavy-Duty Metal
Used With = Alternate Action Maintained Contacts, Electronic Duty Contact Blocks, Quick Connect
Contact Blocks, Screw Terminal Contact Blocks
Mount Style = Panel
Contact Related Features:
Approved Standards = NEMA 1, 12 and 13
Housing Related Features:
Bushing Style = Bayonet (Wobble)
Configuration Related Features:
Operating Function = Momentary
Number of Actuators = Single
Illuminated = No
Frame Color = Black
Industry Standards:
RoHS/ELV Compliance
= RoHS compliant, ELV compliant
Lead Free Solder Processes
= Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS compliant
Other:
Brand = Alcoswitch
