www.ti.com
ABSOLUTE MAXIMUM RATINGS
over operating free-air temperature range (unless otherwise noted)
OPERATING CHARACTERISTICS
over operating free-air temperature range (unless otherwise noted)
SUPPORTED COMMAND SET
RF-HDT-DVBE-N0
SCBS858–FEBRUARY 2007
UNIT
°
C
°
C
Operating temperature
Storage temperature
–25 to 90
–40 to 120 (160
°
C for total 50 hours, 220
°
C for total 30 s)
PARAMETER
RF-HDT-DBE-N0
UNIT
Supported Standard
Resonance Frequency (at 25
°
C)
Typ. required activation field strength to read (at 25
°
C) 112
Typ. required activation field strength to write (at
25
°
C)
Factory programmed Read Only Number
Memory (user programmable)
Typical programming cycles (at 25
°
C)
Data retention time (at 25
°
C)
Simultaneous Identification of Tags
Dimensions
Weight
Case Material
Protection Class
Vibration
Mechanical Shock
ISO/IEC 15693-2,-3; ISO/IEC 18000-3
13.56 MHz
±
300 kHz
dB
μ
A/m
115
dB
μ
A/m
64
256 bits organized in 8
×
32-bit blocks
100,000
> 10 years
Up to 50 tags per second (reader/antenna dependent)
22
±
0.2 mm
×
3
±
0.2 mm
2.1
±
0.2
PPS, black
IP 68
ISO/IEC 68.2.6 (10 g, 10..2000 Hz, 3 axis, 2.5 h)
ISO/IEC 68.2.27 (100 g, 6 ms, 6 axis, 20 times per axis)
Axial compression strength: 1000N (10 s, static)
Radial compression strength: 500N (10 s, static)
Isostatic water pressure: 45 bar (10 h)
Typical chemicals used in laundry and dry-cleaning
processes
1000 units in bulk
bits
grams
Mechanical Stability
Chemical Resistance
Delivery
REQUEST MODE
(1)(2)
REQUEST
REQUEST
CODE
NON-
OPTIONAL
FLAG
INVENTORY
ADDRESSED
AFI
ADDRESSED
ISO 15693 Mandatory
and Optional Commands
Inventory
Stay Quiet
Read_Single_Block
Write_Single_Block
Lock_Block
0x01
0x02
0x20
0x21
0x22
ü
-
-
-
-
-
-
-
ü
-
-
-
-
0/-
0/-
-/1
-/1
-/1
ü
ü
ü
ü
ü
ü
ü
(1)
(2)
ü
: Implemented
-: Not applicable
2
