www.ti.com
(R2) + 5.11
100
D%
* 10.22 (kW)
(2)
I
O(max) +
V
O
I
O(rated)
V
A
(3)
L
O
A
D
Sense (–)
Sense (+)
+
(R2)
Adjust
Down
PTEA404120A
Sense(+)
Sense(–)
5
2
7
Adjust
8
6
4
1
3
+VI
VI
+VI
VI
CO
330
F
+VO
VO
+VO
VO
Remote
On/Off
R1
Adjust
Up
SLTS274 – DECEMBER 2006
Where:
% = Amount of adjustment in %
VO = Original set-point voltage
Notes:
1. Use only a single 1% resistor in either the R1 or (R2) location. Place the resistor as close to the converter
as possible.
2. If the output voltage is increased, the maximum load current must be derated according to the following
equation.
Where:
V
O = Original set-point voltage
V
A = Adjusted output voltage (measured between pins 8 and 4)
In any instance, the load current must not exceed the converter's maximum rated output current of 4.2 A.
3. The overvoltage threshold is fixed, and is set approximately 20% above the nominal output voltage.
Adjusting the output voltage higher reduces the voltage margin between the adjusted output voltage and
the overvoltage (OV) protection threshold. This could make the module sensitive to OV fault detection, as
a result of random noise and load transients.
Figure 7.
10
