參數資料
| 型號： | PI3PCIE2215ZHE |
| 廠商： | Pericom |
| 文件頁數： | 4/10頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC MUX/DEMUX 2X1 28TQFN |
| 標準包裝： | 490 |
| 系列： | PCI Express, TDP™ |
| 功能： | 多路復用器/多路分解器 |
| 電路： | 4 x 2:1 |
| 導通狀態電阻： | 12 歐姆 |
| 電壓電源： | 單電源 |
| 電壓 - 電源，單路/雙路(±)： | 3 V ~ 3.6 V |
| 電流 - 電源： | 2.5mA |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 28-VFQFN 裸露焊盤 |
| 供應商設備封裝： | 28-TQFN-EP（3.5x5.5） |
| 包裝： | 管件 |
3
PI3PCIE2215
3.3V, PCI Express, 1-Lane,
2:1 Mux/DeMux Switch
PS9069
08/03/09
Recommended Operating Conditions
Symbol
Parameter
Conditions
Min
Typ
Max
Units
VDD
3.3V Power Supply
3.0
3.3
3.6
V
IDD
Total current from VDD
3.3V supply
0
2.5
mA
TCASE
Case temperature range
for operation within spec.
-40
85
Celsius
Electrical Characteristics
Storage Temperature ....................................................–65°C to +150°C
Supply Voltage to Ground Potential ................................–0.5V to +4.6V
DC Input Voltage .............................................................. –0.5V to VDD
DC Output Current .......................................................................120mA
Power Dissipation ........................................................................... 0.5W
Note: Stresses greater than those listed under MAXIMUM
RATINGS may cause permanent damage to the device. This
is a stress rating only and functional operation of the device
at these or any other conditions above those indicated in the
operational sections of this specication is not implied. Expo-
sure to absolute maximum rating conditions for extended
periods may affect reliability.
Maximum Ratings
(Above which useful life may be impaired. For user guidelines, not tested.)
DC Electrical Characteristics (TA = –40°C to +85°C, VDD = 3.3V ± 10%)
Parameter
Description
Test Conditions
Min
Typ(1)
Max
Units
VIH-SEL(2)
Input high level, SEL input
2.0
3.6
V
VIL-SEL(2)
Input Low Level, SEL
input
0
0.8
V
IIN_SEL(2)
Input Leakage Current,
SEL input
Measured with input at VIH-SEL max and
VIL-SEL min
–10
10
μA
RON
On Resistance
VDD = Min., VIN = 1.3V, IIN = 40mA
12
Ohm
CON
On Channel Capacitance
VIN = 0, VDD = 3.3V
2.0
pF
Note:
1.
Typical values are at VDD = 3.3V, TA = 25°C ambient and maximum loading.
Dynamic Electrical Characteristics for xI±, xOy±
Parameter
Description
Test Conditions
Min.
Typ.(1)
Max.
Units
DDIL
Differential Insertion Loss
f=1.2GHz
f=2.5GHz
f=5.0GHz
f=7.5GHz
-1.5
-2.0
-5.0
-9.0
dB
DDILOFF
Differential Off Isolation
f= 0 to 3.0GHz
-20.0
DDRL
Differential Return Loss
f= 0 to 2.8GHz
f= 2.8 to 5.0GHz
f= 5.0 to 7.5GHz
-14.0
-8.0
-4.0
DDNEXT
Near End Crosstalk
f= 0 to 2.5GHz
f= 2.5 to 5.0GHz
f= 5.0 to 7.5GHz
-32.0
-26.0
-20.0
09-0033
