5
PI2PCIE2214
PCI Express 2.0, 1-lane,
4:1 Mux/DeMux Switch
PS8989A
12/04/09
+
–
+
–
BALANCED
PORT1
DUT
+
–
50
+
–
BALANCED
PORT2
50
Diff. Near End Xtalk Test Circuit
+
–
+
–
BALANCED
PORT1
BALANCED
PORT2
DUT
+
–
50
Diff. Off Isolation Test Circuit
+
–
+
–
BALANCED
PORT1
BALANCED
PORT2
DUT
Diff. Insertion Loss and Return Test
Circuit
Switching Waveforms
Voltage Waveforms Enable and Disable Times
tPLZ
VDD/2
VDD
VOH
0V
VOL
VDD/2
VOH –0.3V
VOL +0.3V
VDD/2
tPHZ
tPZL
tPZH
Output
VOL
VOH
SEL
Switch Positions
Test
Switch
tPLZ, tPZL
2 x VDD
tPHZ, tPZH
GND
Prop Delay
Open
4
200
2
P
Test Circuit for Electrical Characteristics(1-5)
Notes:
1.
CL = Load capacitance: includes jig and probe capacitance.
2.
RT = Termination resistance: should be equal to ZOUT of the Pulse Generator
3.
Output 1 is for an output with internal conditions such that the output is low except when disabled by the output control.
output 2 is for an output with internal conditions such that the output is high except when disabled by the output control.
4.
All input impulses are supplied by generators having the following characteristics: PRR ≤ MHz, ZO = 50Ω, tR ≤ 2.5ns, tF ≤ 2.5ns.
5.
The outputs are measured one at a time with one transition per measurement.
09-0107
