參數資料
| 型號： | NCS2004SQ3T2G |
| 廠商： | ON Semiconductor |
| 文件頁數： | 6/13頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC OP AMP R-R 3.5MHZ SC-88A |
| 標準包裝： | 1 |
| 放大器類型： | 通用 |
| 電路數： | 1 |
| 輸出類型： | 滿擺幅 |
| 轉換速率： | 2.6 V/µs |
| 增益帶寬積： | 3.5MHz |
| 電流 - 輸入偏壓： | 45pA |
| 電壓 - 輸入偏移： | 500µV |
| 電流 - 電源： | 400µA |
| 電流 - 輸出 / 通道： | 13mA |
| 電壓 - 電源，單路/雙路(±)： | 2.5 V ~ 16 V，±1.25 V ~ 8 V |
| 工作溫度： | -40°C ~ 105°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 6-TSSOP（5 引線），SC-88A，SOT-353 |
| 供應商設備封裝： | SC-88A |
| 包裝： | 標準包裝 |
| 其它名稱： | NCS2004SQ3T2GOSDKR |
NCS2004
http://onsemi.com
2
MAXIMUM RATINGS
Symbol
Rating
Value
Unit
VDD
Supply Voltage
16.5
V
VID
Input Differential Voltage
$Supply Voltage
V
VI
Input Common Mode Voltage Range
0.2 V to (VDD +
0.2 V)
V
II
Maximum Input Current
$10
mA
IO
Output Current Range
$100
mA
Continuous Total Power Dissipation (Note 1)
200
mW
TJ
Maximum Junction Temperature
150
°C
qJA
Thermal Resistance
333
°C/W
Tstg
Operating Temperature Range (freeair)
40 to 105
°C
Tstg
Storage Temperature
65 to 150
°C
Mounting Temperature (Infrared or Convection 20 sec)
260
°C
VESD
Machine Model
Human Body Model
300
2000
V
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the
Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may
affect device reliability.
1. Continuous short circuit operation to ground at elevated ambient temperature can result in exceeding the maximum allowed junction
temperature of 150°C. Output currents in excess of 45 mA over long term may adversely affect reliability. Shorting output to either V+
or V will adversely affect reliability.
DC ELECTRICAL CHARACTERISTICS (VDD = 2.5 V, 3.3 V, 5 V and $5 V, TA = 25°C, RL w 10 kW unless otherwise noted)
Parameter
Symbol
Conditions
Min
Typ
Max
Unit
Input Offset Voltage
VIO
VIC = VDD/2, VO = VDD/2, RL = 10 kW, RS = 50 W
0.5
5.0
mV
TA = 40°C to +105°C
7.0
Offset Voltage Drift
ICVOS
VIC = VDD/2, VO = VDD/2, RL = 10 kW, RS = 50 W
2.0
mV/°C
Common Mode
Rejection Ratio
CMRR
0 V v VIC v VDD 1.35 V, RS = 50 W
VDD = 2.5 V
55
94
dB
TA = 40°C to +105°C
52
0 V v VIC v VDD 1.35 V, RS = 50 W
VDD = 5 V
65
130
TA = 40°C to +105°C
62
0 V v VIC v VDD 1.35 V, RS = 50 W
VDD = $5 V
69
140
TA = 40°C to +105°C
66
Power Supply
Rejection Ratio
PSRR
VDD = 2.5 V to 16 V, VIC = VDD/2, No Load
70
135
dB
TA = 40°C to +105°C
65
Large Signal
Voltage Gain
AVD
VO(pp) = VDD/2, RL = 10 kW
VDD = 2.5 V
90
130
dB
TA = 40°C to +105°C
76
VO(pp) = VDD/2, RL = 10 kW
VDD = 3.3 V
92
123
TA = 40°C to +105°C
76
VO(pp) = VDD/2, RL = 10 kW
VDD = 5 V
95
127
TA = 40°C to +105°C
86
VO(pp) = VDD/2, RL = 10 kW
VDD = $5 V
95
130
TA = 40°C to +105°C
90
Input Bias Current
IB
VDD = 5 V, VIC = VDD/2, VO = VDD/2,
RS = 50 W
TA = 25°C
45
150
pA
TA = 105°C
1000
