Document No. 008-0278-0
Page 3 - 5
Rev. C
CTS Electronic Components, Inc.
171 Covington Drive
Bloomingdale, IL 60108
MXO45LV/ MXO45HSLV
Metal DIP Clock Oscillator
MECHANICAL SPECIFICATIONS
PACKAGE DRAWING
MARKING INFORMATION
1. XXXMXXXX - Frequency marked with 4 significant digits after the ‘M’.
2. ST – Frequency stability/temperature code.
3. YYWW – Date code, YY – year, WW – week.
4. ** - Manufacturing Site Code.
NOTES
CMOS/ TTL OUTPUT WAVEFORM
TEST CIRCUIT, CMOS LOAD
+
ENABLE TRUTH TABLE
PIN 1
Logic ‘1’
Open
Logic ‘0’
PIN 5 or PIN 8
Output
Output
High Imp.
D.U.T. PIN ASSIGNMENTS
SYMBOL
EOH
Enable Input
GND
Circuit & Package Ground
Output
RF Output
V
CC
Supply Voltage
PIN
1
7 or 4
8 or 5
14 or 8
DESCRIPTION
(Reference Ordering Information.)
1. Lead finish (e1), SnAgCu.
2. Reflow conditions per JEDEC J-STD-020.
PERIOD (T)
90%, 80%, 2.4V
50%, 1.5V
10%, 20%, 0.5V
DUTY CYCLE = t/T x 100 (%)
V
V
OH
OL
Tr
Tf
UPTIME (t)
POWER
SUPPLY
-
+
-
-
+
VM
mA
0.01uF
D.U.T.
14 or 8
8 or 5
1
7 or 4
C
L
capacitance.
Enable Input or N.C.
DIP-14
1.524
.060
20.574
.810
.017/.020
.432/.508
6.350 ± .508
.250 ± .020
5.080
.200
MAX
.028 ± .013
INCH
KEY:
MM
.711 ± .330
MAX
.300 ± .005
7.620 ± .127
.510
12.954
FOR REFERENCE
ONLY. THE NUMBERS
ARE NOT MARKED
ON BOTTOM.
8
14
1.524
.060
15.240 ± .127
.600 ± .005
TYP.
TYP.
DENOTES PIN 1
1
7
MAX
MXO45LV
XXXMXXXX
CTS ST
●
YYWW **
