MicroSMP
Vishay General Semiconductor
www.vishay.com
New MicroSMP Miniature, High-Power-Density Package for
Schottky Rectifiers and Transient Voltage Suppressors (TVS)
VMN-PT0073-07XX
FEATURES
More power in a smaller package
Schottky rectifiers rated up to 1 a at 110 °c lead temperature
tVS rated up to 100 W at 10/1000 μs waveform
features solder pads that are compatible with other SMd devices
no modification is needed to the PcB layout when they are used as higher-performing upgrades to existing devices
improve on all previous tVS products in similar package types by combining eSd transient protection with a superior
surge clamping capability
Vishay P/N
IF
(A)
VRRM
( V )
VF at IF and TJ
IFSM
( A )
TJ max
( °C )
VF
(V)
IF
(A)
TJ
(°C)
MSS1P2L
1
20
0.40
1
125
25
150
MSS1P3L
1
30
0.40
1
125
25
MSS1P3
1
30
0.46
1
125
25
MSS1P4
1
40
0.46
1
125
25
MSS1P5
1
50
0.60
1
125
25
MSS1P6
1
60
0.60
1
125
25
Rectifier Specification
Vishay P/N
Stand-off
Voltage
Breakdown
Voltage
At 10/1000 s
8/20 s
Pd
(W)
TJ max
( °C )
VWM
(V)
VBR
(V)
PPPM
(W)
VC
IPPM
(A)
PPPM
(W)
VC
IPPM
(A)
MSP3V3
3.3
4.1 at 1 ma
100
7.3
13.7
825
11
75
1
150
MSP5.0A
5.0
6.7 at 10 ma
100
9.2
10.9
825
14.5
57
1
150
TVS Specification
KEy APPLICATIONS:
Schottky MicroSMP rectifiers
Secondary rectification and freewheeling diode functions for miniature ac-to-dc and dc-to-dc converters
flywheel and polarity protection for miniature power converters and portable electronic equipment such as digital
cameras, MP3 players, navigation systems, GPS, and cellular phones
Polarity protection of power lines and signal lines for industrial systems
MicroSMP tVS
Power and signal line protection for microprocessors, signal processing ics, and logic circuits
high-power voltage regulation for non-sensitive input voltage circuits in automotive and industrial electronics
