2
RF Device Data
Freescale Semiconductor
MRF8S9220HR3 MRF8S9220HSR3
Table 3. ESD Protection Characteristics
Test Methodology
Class
Human Body Model (per JESD22-A114)
1C (Minimum)
Machine Model (per EIA/JESD22-A115)
A (Minimum)
Charge Device Model (per JESD22-C101)
IV (Minimum)
Table 4. Electrical Characteristics (TA = 25°C unless otherwise noted)
Characteristic
Symbol
Min
Typ
Max
Unit
Off Characteristics
Zero Gate Voltage Drain Leakage Current
(VDS = 70 Vdc, VGS = 0 Vdc)
IDSS
—
10
μAdc
Zero Gate Voltage Drain Leakage Current
(VDS = 28 Vdc, VGS = 0 Vdc)
IDSS
—
1
μAdc
Gate-Source Leakage Current
(VGS = 5 Vdc, VDS = 0 Vdc)
IGSS
—
1
μAdc
On Characteristics
Gate Threshold Voltage
(VDS = 10 Vdc, ID = 400 μAdc)
VGS(th)
1.5
2.2
3
Vdc
Gate Quiescent Voltage
(VDD = 28 Vdc, ID = 1600 mAdc, Measured in Functional Test)
VGS(Q)
2.3
3.1
3.8
Vdc
Drain-Source On-Voltage
(VGS = 10 Vdc, ID = 4 Adc)
VDS(on)
0.1
0.2
0.3
Vdc
Functional Tests (1) (In Freescale Test Fixture, 50 ohm system) VDD = 28 Vdc, IDQ = 1600 mA, Pout = 65 W Avg., f = 960 MHz,
Single-Carrier W-CDMA, IQ Magnitude Clipping, Input Signal PAR = 7.5 dB @ 0.01% Probability on CCDF. ACPR measured in 3.84 MHz
Channel Bandwidth @ ±5 MHz Offset.
Power Gain
Gps
18.0
19.4
21.0
dB
Drain Efficiency
ηD
34.0
35.7
—
%
Output Peak-to-Average Ratio @ 0.01% Probability on CCDF
PAR
5.7
6.1
—
dB
Adjacent Channel Power Ratio
ACPR
—
-37.4
-35
dBc
Input Return Loss
IRL
—
-13
-8
dB
Typical Broadband Performance (In Freescale Test Fixture, 50 ohm system) VDD = 28 Vdc, IDQ = 1600 mA, Pout = 65 W Avg.,
Single-Carrier W-CDMA, IQ Magnitude Clipping, Input Signal PAR = 7.5 dB @ 0.01% Probability on CCDF. ACPR measured in 3.84 MHz
Channel Bandwidth @ ±5 MHz Offset.
Frequency
Gps
(dB)
hD
(%)
Output PAR
(dB)
ACPR
(dB)
IRL
(dB)
920 MHz
19.7
35.1
6.1
-37.4
-13
940 MHz
19.8
35.3
6.2
-37.5
-24
960 MHz
19.4
35.7
6.1
-37.4
-13
1. Part internally matched both on input and output.
(continued)
