Rating
B112
I
Product Specifications
Current rating
(Note1)
Voltage rating
AWG
#
16 : 7A
AWG
#
18 : 6A
AWG
#
20 : 5A
AWG
#
22 : 4A
300V AC
Cable Size
Storage Temperature Range
Storage Moisture Range
Operating Temperature Range
Operating Moisture Range
-10
to
+60
(Note3)
-
40
to
70
%
(Note3)
-30
to
+85
(Note2)
-
40
to
80
%
I
UL CSA Safety Standard File No.
UL
:E52653
CSA
:LR95109
Item
Specification
Condition
1. Insulation Resistance
2. Withstanding voltage
3. Contact Resistance
4.
Single Insertor/Extraction Force
0.4N(40gf) min., 4.9N(500gf) max.
5. Vibration
No electrical discontinuity of 1μs or more
6.
Humidity (Steady state)
Contact resistance: 30m
ohms
max.Insulation resistance: 500M
ohms
min.
1000M
ohms
min
500V DC
1500V AC/1 minute
100mA
Measured at the steel pin with 1.52
∞
0.76
±
0.002mm
No flashover or insulation breakdown.
30m
ohms
max
Frequency: 10 to 55 Hz, single amplitude of 0.75 mm, 2 hours in each of the 3 directions.
96 hours at temperature of 40 and humidity of 90% to 95%
(-55
: 30 minutes
5
to
35
: 10 minutes
(-
85
: 30 minutes
5
to
35
: 10 minutes) 5 cycles
30 cycles
7. Temperature Cycle
Contact resistance: 30m
ohms
max:Insulation resistance: 1000M
ohms
min.
8.
Durability (Mating/un-mating)
Contact resistance: 30m
ohms
9.
Resistance to Soldering heat
No deformation of components affecting performance.
Flow: 250 for 10 seconds
Manual soldering: 300 for 3 seconds
Rating
I
Material
Product
Part
Material
Treatment
White (Natural)
Tin plated
White (Natural)
Tin plated
Remarks
UL94V-0
–––––
UL94V-0
–––––
Crimping Socket
Insulator
Contact
Insulator
Contact
Polyamide resin
Phosphor copper
Polyamide resin
Brass
Crimping Contact for Socket
Pin Header
Current rating
Voltage rating
AWG
#
16
to #
18 : 6A
AWG
#
20
to #
22 : 4A
30V AC
Cable Size
Standard Value Applicant to the UL CSA Safety Standard
Note 1:
The rated current will be changed according to applicable cable sizes. The header rating only is 7A.
Note 2: Includes temperature rise caused by current flow.
Note 3: The term "storage" refers to products stored for long period of time prior to mounting and use. Operating Temperature Range and
Humidity range covers non conducting condition of installed connectors in storage, shipment or during transportation.
I
Ordering Information
G
Connector
G
Contact
MDF6
-
*
DS - 3.5 C
q
e
w
r
t
MDF6
-
1618 - SCF
q
w
q
Applicable Cable Size
1618 : AWG
#
16
to #
18
2022 : AWG
#
20
to #
22
w
Packaging Type
SCF: Socket Contact, Reel
SC : Socket Contact, Bag
q
Series Name
w
Number of Contacts
: 4
to
20
e
Connector Type
DS : Double row socket
DP : Double row pin header
: MDF 6
r
Contact Pitch
t
Contact type
C
: Crimping socket
DSA:
Straight dip
DS : Right angle dip
: 3.5mm
The product information in this catalog is for reference only. Please request the Engineering Drawing for the most current and accurate design information.
All non-RoHS products have been discontinued, or will be discontinued soon. Please check the products status on the Hirose website RoHS search at www.hirose-connectors.com, or contact your Hirose sales representative.
