Electrical Characteristics
MC9S08GW64 Series MCU Data Sheet, Rev. 1
PRELIMINARY-SUBJECT TO CHANGE WITHOUT NOTICE
Freescale Semiconductor
13
3.6
DC Characteristics
This section includes information about power supply requirements and I/O pin characteristics.
Table 7. ESD and Latch-Up Protection Characteristics
No.
Rating1
1 Parameter is achieved by design characterization on a small sample size from typical devices
under typical conditions unless otherwise noted.
Symbol
Min
Max
Unit
1
Human body model (HBM)
VHBM
±1500
—
V
2
Machine Model (MM)
VMM
±200
—
V
3
Charge device model (CDM)
VCDM
±500
—
V
4
Latch-up current at TA = 85°CILAT
±100
—
mA
Table 8. DC Characteristics
Num C
Characteristic
Symbol
Condition
Min
Typ1
Max
Unit
1
Operating Voltage
1.8
3.6
V
2
C Output high
voltage
All non-LCD pins
low-drive strength
VOH
VDD >1.8 V
ILoad = –0.6 mA
VDD – 0.5
—
V
P
All non-LCD pins
high-drive strength
VDD > 2.7 V
ILoad = –10 mA
VDD – 0.5
—
CVDD > 1.8 V
ILoad = –3 mA
VDD – 0.5
—
3
C Output high
voltage
All LCD/GPIO pins
low-drive strength
VOH
VDD >1.8 V
ILoad = –0.5 mA
VDD – 0.5
—
V
P
All LCD/GPIO pins
high-drive strength
VDD > 2.7 V
ILoad = –2.5 mA
VDD – 0.5
—
CVDD > 1.8 V
ILoad = –1 mA
VDD – 0.5
—
4
D Output high
current
Max total IOH for all ports
IOHT
——
100
mA
5
C Output low
voltage
All non-LCD pins
low-drive strength
VOL
VDD > 1.8 V
ILoad = 0.6 mA
——
0.5
V
P
All non-LCD pins
high-drive strength
VDD > 2.7 V
ILoad = 10 mA
——
0.5
CVDD > 1.8 V
ILoad = 3 mA
——
0.5
6
C Output low
voltage
All LCD/GPIO pins
low-drive strength
VOL
VDD > 1.8 V
ILoad = 0.5 mA
——
0.5
V
P
All LCD/GPIO pins
high-drive strength
VDD > 2.7 V
ILoad = 3 mA
——
0.5
CVDD > 1.8 V
ILoad = 1 mA
——
0.5
7
D Output low
current
Max total IOL for all ports
IOLT
——
100
mA
