7
MB90620A Series
(Continued)
Pin no.
Pin name
Circuit type
Function
18
P42
L
(CMOS/H)
General-purpose I/O port
This function is available when the timer output from timer 0 is
disabled.
INT7
External interrupt request input pin
When external interrupts are enabled, these inputs may be used at
any time; therefore, it is necessary to stop output by other functions
on these pins, except when using them for output deliberately.
TIO0
Timer input pin
The data on this pin is used as event count signal for timer 0.
Timer output pin
This function is available when the timer output from timer 0 is
enabled.
19
P43
E
(CMOS/H)
General-purpose I/O port
This function is available when the timer output from timer 1 is
disabled.
TIO1
Timer input pin
The data on this pin is used as event count signal for timer 1.
Timer output pin
This function is available when the timer output from timer 1 is
enabled.
20
P44
E
(CMOS/H)
General-purpose I/O port
This function is available when the timer output from timer 2 is
disabled.
TIO2
Timer input pin
The data on this pin is used as event count signal for timer 2.
Timer output pin
This function is available when the timer output from timer 2 is
enabled.
21
VCC
Power supply
Digital circuit power supply pin
22, 23
P45, P46
H
(CMOS)
Open-drain I/O ports
24 to 27
V0 to V3
Power supply
LCDC reference power supply pins
28 to 31
COM0 to
COM3
K
LCDC common pins
32
AVCC
Power supply
Analog circuit power supply pin
This power supply must only be turned on or off when electric
potential of AVCC or greater is applied to VCC.
33
AVRH
Power supply
Analog circuit reference voltage input pin
This pin must only be turned on or off when electric potential of
AVRH or greater is applied to AVCC.
34
AVRL
Power supply
Analog circuit reference voltage input pin
35
AVSS
Power supply
Analog circuit power supply (GND) pin
