Table 3. Reset/Watchdog Timeout Periods
MAX6316–MAX6322
__Ordering Information (continued)
Note: These devices are available with factory-set VCC reset
thresholds from 2.5V to 5V, in 0.1V increments. Insert the
desired nominal reset threshold (25 to 50, from Table 1) into the
blanks following the letters UK. All devices offer factory-pro-
grammed reset timeout periods. Insert the letter corresponding
to the desired reset timeout period (A, B, C, or D from Table 3)
into the blank following the reset threshold suffix. Parts that offer
a watchdog feature (see Selector Guide) are factory-trimmed to
one of four watchdog timeout periods. Insert the letter corre-
sponding to the desired watchdog timeout period (W, X, Y, or Z
from Table 3) into the blank following the reset timeout suffix.
5-Pin P Supervisory Circuits with
Watchdog and Manual Reset
______________________________________________________________________________________
13
W
4.3
6.3
9.3
ms
X
71
102
153
Y
1.12
1.6
2.4
Z
17.9
25.6
38.4
s
RESET TIMEOUT PERIODS
WATCHDOG TIMEOUT
TRANSISTOR COUNT: 191
SUBSTRATE IS INTERNALLY CONNECTED TO V+
Chip Information
s
2.24
1.60
1.12
D
280
200
140
C
40
30
20
B
2
1.6
1
A
UNITS
MAX
TYP
MIN
SUFFIX
ms
Note: Thirteen standard versions are available, with a required order increment of 2500 pieces. Sample stock is generally held on stan-
dard versions only. The required order increment for nonstandard versions is 10,000 pieces. Contact factory for availability.
PART
RESET
THRESHOLD (V)
MINIMUM
RESET
TIMEOUT (ms)
TYPICAL
WATCHDOG
TIMEOUTS (s)
SOT
TOP
MARK
MAX6320PUK46CY-T
4.63
140
1.6
ACDN
MAX6321HPUK46CY-T
4.63
140
1.6
ACGL
MAX6322HPUK46C-T
4.63
140
1.6
ACGN
Table 2. Standard Versions (continued)
Devices are available in both leaded and lead-free packaging.
Specify lead-free by replacing “-T” with “+T” when ordering.
/V denotes an automotive qualified part.
PACKAGE TYPE
PACKAGE CODE
DOCUMENT NO.
5 SOT23
U5-2
Package Information
For the latest package outline information and land patterns,
go to www.maxim-ic.com/packages. Note that a “+”, “#”, or
“-” in the package code indicates RoHS status only. Package
drawings may show a different suffix character, but the drawing
pertains to the package regardless of RoHS status.
PART
TEMP RANGE
PIN-PACKAGE
MAX6319LHUK_ _ _ - T
-40°C to +125°C
5 SOT23
MAX6319MHUK_ _ _- T
-40°C to +125°C
5 SOT23
MAX6320PUK_ _ _ _- T
-40°C to +125°C
5 SOT23
MAX6320PUK_ _ _ _ / V
-40°C to +125°C
5 SOT23
MAX6321HPUK_ _ _ - T
-40°C to +125°C
5 SOT23
MAX6322HPUK_ _ _ - T
-40°C to +125°C
5 SOT23
