參數資料
| 型號： | MAX2038CCQ+T |
| 廠商： | Maxim Integrated Products |
| 文件頁數： | 3/24頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC VGA W/OCTAL MIXER 8CH 100TQFP |
| 產品培訓模塊： | Lead (SnPb) Finish for COTS Obsolescence Mitigation Program |
| 標準包裝： | 250 |
| 類型： | 可變?cè)鲆娣糯笃?br> |
| 應用： | 醫療用超聲波成像，聲納 |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 100-TQFP 裸露焊盤 |
| 供應商設備封裝： | 100-TQFP-EP（14x14） |
| 包裝： | 帶卷 (TR) |
MAX2038
Pin Description
PIN
NAME
FUNCTION
1
CWIN2-
CW Mixer Channel 2 Inverting Differential Input
2
CWIN2+
CW Mixer Channel 2 Noninverting Differential Input
3
VGIN3-
VGA Channel 3 Inverting Differential Input
4
VGIN3+
VGA Channel 3 Noninverting Differential Input
5, 10, 19,
24, 29, 34,
58, 79,
81, 96
GND
Ground
6
CWIN3-
CW Mixer Channel 3 Inverting Differential Input
7
CWIN3+
CW Mixer Channel 3 Noninverting Differential Input
8
VGIN4-
VGA Channel 4 Inverting Differential Input
9
VGIN4+
VGA Channel 4 Noninverting Differential Input
11
CWIN4-
CW Mixer Channel 4 Inverting Differential Input
12
CWIN4+
CW Mixer Channel 4 Noninverting Differential Input
13
EXT_C1
External Compensation. Connect a 4.7μF capacitor to ground as close as possible to the pin to
bypass the internal biasing circuitry.
14
EXT_C2
External Compensation. Connect a 4.7μF capacitor to ground as close as possible to the pin to
bypass the internal biasing circuitry.
15
EXT_C3
External Compensation. Connect a 4.7μF capacitor to ground as close as possible to the pin to
bypass the internal biasing circuitry.
16, 42, 46,
54, 72,
82, 87
VCC
5V Power Supply. Connect to an external +5V power supply. Bypass each VCC supply to ground
with 0.1μF capacitors as close as possible to the pins.
17
VGIN5-
VGA Channel 5 Inverting Differential Input
18
VGIN5+
VGA Channel 5 Noninverting Differential Input
20
CWIN5-
CW Mixer Channel 5 Inverting Differential Input
21
CWIN5+
CW Mixer Channel 5 Noninverting Differential Input
22
VGIN6-
VGA Channel 6 Inverting Differential Input
23
VGIN6+
VGA Channel 6 Noninverting Differential Input
25
CWIN6-
CW Mixer Channel 6 Inverting Differential Input
26
CWIN6+
CW Mixer Channel 6 Noninverting Differential Input
27
VGIN7-
VGA Channel 7 Inverting Differential Input
28
VGIN7+
VGA Channel 7 Noninverting Differential Input
30
CWIN7-
CW Mixer Channel 7 Inverting Differential Input
31
CWIN7+
CW Mixer Channel 7 Noninverting Differential Input
32
VGIN8-
VGA Channel 8 Inverting Differential Input
33
VGIN8+
VGA Channel 8 Noninverting Differential Input
35
CWIN8-
CW Mixer Channel 8 Inverting Differential Input
36
CWIN8+
CW Mixer Channel 8 Noninverting Differential Input
Ultrasound VGA Integrated
with CW Octal Mixer
______________________________________________________________________________________
11
