MACH 1 & 2 Families
7
Macrocell
There are two fundamental types of macrocell: the output macrocell and the buried macrocell. The
buried macrocell is only found in MACH 2 devices. The use of buried macrocells effectively
doubles the number of macrocells available without increasing the pin count.
Both macrocell types can generate registered or combinatorial outputs. For the MACH 2 series,
a transparent-low latch conguration is provided. If the register is used, it can be congured as
a T-type or a D-type ip-op. Register and latch functionality is dened in Table 9.
Programmable polarity (for output macrocells) and the T-type ip-op both give the software a
way to minimize the number of product terms needed. These choices can be made automatically
by the software when it ts the design into the device.
Table 7. Logic Allocation for MACH211(SP) and MACH231(SP)
Macrocell
Available Clusters
Macrocell
Available Clusters
Output
Buried
Output
Buried
M0
M1
C0, C1, C2
C0, C1, C2, C3
M8
M9
C7, C8, C9, C10
C8, C9, C10, C11
M2
M3
C1, C2, C3, C4
C2, C3, C4, C5
M10
M11
C9, C10, C11, C12
C10, C11, C12, C13
M4
M5
C3, C4, C5, C6
C4, C5, C6, C7
M12
M13
C11, C12, C13, C14
C12, C13, C14, C15
M6
M7
C5, C6, C7, C8
C6, C7, C8, C9
M14
M15
C13, C14, C15
C14, C15
Table 8. Logic Allocation for MACH221(SP)
Macrocell
Available Clusters
Macrocell
Available Clusters
Output
Buried
Output
Buried
M0
M1
C0, C1, C2
C0, C1, C2, C3
M6
M7
C5, C6, C7, C8
C6, C7, C8, C9
M2
M3
C1, C2, C3, C4
C2, C3, C4, C5
M8
M9
C7, C8, C9, C10
C8, C9, C10, C11
M4
M5
C3, C4, C5, C6
C4, C5, C6, C7
M10
M11
C9, C10, C11
C10, C11
Table 9. Register/Latch Operation
Conguration
D/T
CLK/LE
Q+
D-Register
X
0,1,
↓
Q
0
↑
0
1
↑
1
T-Register
X
0,1,
↓
Q
0
↑
Q
1
↑
Q
Latch
X1
Q
00
0
10
1
