TIMING DIAGRAM
PIN DESCRIPTION
PIN No
3, 2, 4, 7,
10, 1, 5, 6,
9, 11
12
SYMBOL
Q0 to Q9
NAME AND FUNCTION
Decoded Outputs
C
OUT
Carry Output (Active
LOW)
Clock Enable Input
(Active LOW)
Clock Input (LOW to
HIGH, Edge-triggered)
Master Reset Input
(Active HIGH)
Ground (0V)
Positive Supply Voltage
13
CKEN
14
CLOCK
15
RESET
8
GND
V
CC
16
IEC LOGIC SYMBOL
M54/M74HC4017
3/12
