PRELIMINAR
Y
Notice:
This
is not
a final
specification.
Some
parametric
limits
are
subject
to change.
3
MITSUBISHI MICROCOMPUTERS
M37735EHLXXXHP
PROM VERSION OF M37735MHLXXXHP
FUNCTIONS OF M37735EHLXXXHP
Memory size
Input/Output ports
Multi-function timers
Interrupts
Clock generating circuit
Power dissipation
Parameter
Functions
Number of basic instructions
103
Instruction execution time
333 ns (the fastest instruction at external clock 12 MHz frequency)
PROM
124 Kbytes
RAM
3968 bytes
P0 – P2, P4 – P8
8-bit ! 8
P3
4-bit ! 1
TA0, TA1, TA2, TA3, TA4
16-bit ! 5
TB0, TB1, TB2
16-bit ! 3
Serial I/O
(UART or clock synchronous serial I/O) ! 3
A-D converter
10-bit ! 1 (8 channels)
Watchdog timer
12-bit ! 1
3 external types, 16 internal types
Each interrupt can be set to the priority level (0 – 7.)
2 circuits built-in (externally connected to a ceramic resonator or a
quartz-crystal oscillator)
Supply voltage
2.7 – 5.5 V
9 mW (at 3 V supply voltage, external clock 12 MHz frequency)
22.5 mW (at 5 V supply voltage, external clock 12 MHz frequency)
Input/Output voltage
5 V
Output current
5 mA
Memory expansion
Maximum 1 Mbytes
Operating temperature range
–40 to 85 °C
Device structure
CMOS high-performance silicon gate process
Package
80-pin plastic molded fine-pitch QFP (80P6D-A;0.5 mm lead pitch)
