No. 6903-8/14
LV23000M
Structure of the DO Control Data (Serial Output Data)
(1) OUT mode
STIND
SDIND
0
UL
C19
C18
C17
C16
C15
C14
C13
C12
C11
C10
C9
C8
C7
C6
C5
C4
C3
C2
C1
C0
0
1
0
1
0
1
0
DI
(1)IN-PORT
(3)IF-CTR
DO
DO Output Data
No.
Control block/data
Description
Related data
Indicates the states of the stereo and SD indicators at the point latched.
The data is latched at the point the devices goes to data output mode (OUT mode).
STIND
← Stereo indicator state: 0: ST on, 1: ST off
SDINC
← SD indicator state: 0: SD on, 1: SD off
(1)
Stereo indicator
SD indicator
Control data
STIND, SDIND
Indicates the state of the unlock detection circuit at the point latched.
UL
← 0: Unlocked
1: Locked or detection stopped mode.
(2)
PLL unlocked data
UL
Indicates the content of the IF counter (20-bit binary counter) at the point latched.
C19
← MSB of the binary counter
C0
← LSB of the binary counter
(3)
IF counter
Binary counter
C19 to C0
UL0
UL1
CTE
GT0
GT1
Address
