3
LTC3803-3
38033fa
Note 1: Stresses beyond those listed under Absolute Maximum Ratings
may cause permanent damage to the device. Exposure to any Absolute
Maximum Rating condition for extended periods may affect device
reliability and lifetime.
Note 2: The LTC3803E-3 is guaranteed to meet specifications from 0
°C to
85
°C. Specifications over the –40°C to 85°C operating temperature range
are assured by design, characterization and correlation with statistical
process controls. The LTC3803I-3 is guaranteed to meet performance
specifications over the –40
°C to 125°C operating temperature range.
Note 3: TJ is calculated from the ambient temperature TA and power
dissipation PD according to the following formula:
TJ = TA + (PD 230°C/W).
DCON(MIN)
Minimum Switch On Duty Cycle
VITH/RUN = 1.3V, VFB = 0.8V
8
9.6
%
DCON(MAX)
Maximum Switch On Duty Cycle
VITH/RUN = 1.3V, VFB = 0.8V
70
80
90
%
tRISE
Gate Drive Rise Time
CLOAD = 3000pF
40
ns
tFALL
Gate Drive Fall Time
CLOAD = 3000pF (Note 7)
40
ns
ISLMAX
Peak Slope Compensation Output Current
(Note 7)
5
μA
tSFST
Soft-Start Time
1.4
ms
The
● indicates specifications which apply over the full operating
temperature range, otherwise specifications are at TA = 25°C. VCC = 8V, unless otherwise noted. (Note 2)
ELECTRICAL CHARACTERISTICS
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNITS
Note 4: Dynamic supply current is higher due to the gate charge being
delivered at the switching frequency.
Note 5: The LTC3803-3 is tested in a feedback loop that servos V
FB to the
output of the error amplifier while maintaing ITH/RUN at the midpoint of
the current limit range.
Note 6: Peak current sense voltage is reduced dependent on duty cycle
and an optional external resistor in series with the SENSE pin (RSL). For
details, refer to the programmable slope compensation feature in the
Applications Information section.
Note 7: Guaranteed by design.
