www.perkinelmer.com/opto
Digital Linescan Camera
PDP-206.01B - 7/2002W Page 5
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
1
19
18
36
Registration Slot
0.126 x 0.09 deep x 0.150 long
-000
2.50
(63.50)
Measurements in inches (Millimeters)
Front View
Registration Hole
0.156 x 0.09 deep
2.50
(63.50)
Registration Hole
0.126 x 0.09 deep
-000
Pixel 1
Figure 4. Outline Drawings
Side View
1.25
(31.75)
1.25
(31.25)
3.20
(31.28)
2.50
(63.50)
CameraLink
Connector
MDR26
Power
Connector
HR10A
Rear View
CameraLink
Rear View
Parallel LVDS
MDR36
Connector
Power
Connector
HR10A
2.50
(63.50)
2.50
(63.50)
2.50
(63.50)
Registration Hole
0.156 x 0.09 deep
Table 3. LD3500 Camera Specifications
Camera Characteristics
Value
Number of Active Pixels
512, 1024, or 2048
Pixel Size
14μm x 14μm
Spectral Response
250-1000 nm
Sensor Window
Glass
Exposure Control
Yes
Antiblooming
Yes
Camera Operation Features
Number of Outputs
1
Communications Protocol
CameraLink (LD35xxPGK-011)
Parallel LVDS (LD35xxPGL-011)
8 bit
Output Depth
Adjustable Gain Range
0 to 24.5 dB (LD35xxPGK-011)
1, 2, 4, 8X (LD352xPGL-011)
PRNU
+/-10%
Dynamic Range
250:1
Maximum Output Rate
20 MHz (LD352xPGx-011)
40 MHz (LD354xPGK-011)
U Mount
Lens Mount
Temperature Requirements
Operating Temperature
-20 to 55 C
Storage Temperature
-40 to 80 C
Power Requirements
Input voltage
12 to 24 VDC
Camera Characteristics
Value
