參數資料
| 型號： | LCP-10G3B4QDRT |
| 元件分類： | 光收發 |
| 英文描述： | FIBER OPTIC TRANSCEIVER, 1260-1355nm, 10000Mbps(Tx), 10000Mbps(Rx), SURFACE MOUNT, LC CONNECTOR |
| 封裝： | ROHS COMPLIANT PACKAGE |
| 文件頁數： | 14/14頁 |
| 文件大小： | 370K |
| 代理商： | LCP-10G3B4QDRT |
LCP-10G3B4QDRx
DELTA ELECTRONICS, INC.
9
Revision: S0
12/11/2009
www.deltaww.com
Timing parameters for SFP+ management
Parameter
Symbol
Min.
Max.
Unit
Note
TX_DISABLE Assert time
t_off
100
sec
1
TX_DISABLE Negate time
t_on
2
msec
2
Time
to
initialize
2-wire
interfase
t_2w_start_up
300
msec
3
Time to initialize
t_start_up
300
msec
4
Time
to
initialize
cooled
module
t_start_up_cooled
90
sec
4
Time to Power Up to Level 2
t_power_level2
300
msec
5
Time to Power Down from
Level 2
T_power_down
300
msec
6
TX_Fault assert
TX_Fault_on
1
msec
7
TX_Fault assert for cooled
module
TX_Fault_on
50
msec
7
TX_Fault Reset
t_reset
10
sec
8
RS0, RS1 rate select timing
for FC
t_RS0_FC,
RS1_FC
500
sec
9
RS0, RS1 rate select timing
non FC
t_RS0, t_RS1
10
msec
9
RX_LOS assert delay
t_los_on
100
sec
10
RX_LOS negate delay
t_los_off
100
sec
11
Notes:
1)
Rising edge of TX_Disable to fall of output signal below 10% of nominal.
2)
Falling edge of TX_Disable to rise of output signal above 90% of nominal. This only applies in normal
operation, not during start up or fault recovery.
3)
From power on or negation of TX_Disable.
4)
From power on or TX_Disable negated during power up, or TX_Fault recovery, until non-cooled power
level 1 part (or non-cooled power level 2 part already enabled at power level 2 for TX_Fault recovery)
is fully operational.
5) From falling edge of stop bit enabling power level 2 until non-cooled module is fully operational.
6) From falling edge of stop bit disabling power level 2 until module is within power level 1 requirements.
7) From Occurrence of fault to assertion of TX_Fault.
8) Time TX_Disable must be held High to reset TX_Fault.
9) From assertion till stable output.
10) From Occurrence of loss of signal to assertion of LOS
11) From Occurrence of presence of signal to negation of RX_LOS.
