LC865520A/16A/12A/08A/04A
2/19
(4) Ports
- Input/output ports
Input/output programmable in a bit
- Maximum 15V withstand input/output port
Input/output port programmable in nibble units
(When the N-channel open drain output is selected, the data in a bit can be inputted.)
Input/output port programmable in a bit
- Input ports
(5) AD converter
- 8-channel × 8-bit AD converter
(6) Serial-interface
- 1 channel × 16-bit serial-interface (8-bit transmission available by program)
- 1 channel × 8-bit serial-interface
LSB first/MSB first function available
- Internal 8-bit baud-rate generator in common with two serial-interface circuits
(7) Timer
- Timer 0
16-bit timer/counter
2-bit prescaler + 8-bit programmable prescaler
Mode 0 : Two 8-bit timers with programmable prescaler
Mode 1 : 8-bit timer with programmable prescaler + 8-bit counter
Mode 2 : 16-bit timer with programmable prescaler
Mode 3 : 16-bit counter
The resolution of Timer is t
CYC. (
t
CYC: cycle time)
- Timer 1
16-bit timer/PWM
Mode 0 : Two 8-bit timers
Mode 1 : 8-bit timer + 8-bit PWM
Mode 2 : 16-bit timer
Mode 3 : Variable-bit PWM (9-16bits)
In Mode 0 and Mode 1,the resolution of Timer and PWM is t
CYC.
In Mode 2 and Mode 3,the resolution of Timer and PWM selectable: t
CYC or 1/2
t
CYC by program.
- Base timer
Every 500ms overflow system for a clock application (using 32.768kHz crystal oscillation for Base timer clock)
Every 976
μ
s, 3.9ms, 15.6ms, 62.5ms overflow system (using 32.768kHz crystal oscillation for Base timer clock)
The Base timer clock selectable; 32.768kHz crystal oscillation, System clock, and programmable prescaler output of
Timer 0
(8) Buzzer output
- The Buzzer sound frequency selectable; 4KHz, 2KHz (using 32.768kHz crystal oscillation for Base
timer clock)
(9) Remote-control receiver circuit (Shares with P73/INT3/T0IN terminal)
- Noise Rejection function (the time constant of noize rejection filter: 1t
CYC/16
t
CYC/64
t
CYC
)
(t
CYC: instruction cycle time
)
- Switch Polarity function
(10) Watchdog timer
- The watchdog timer is taken on RC outside
- Watchdog timer operation selectable: interrupt system, system reset
: 3 ports (16 terminals : port 1,7,8)
: 2 ports (15 terminals)
: 1 port (8 terminals : port 0)
: 1 port (7 terminals : port 3)
: 2 ports (6 terminals : port 7,8)
