LC74763, 74763M
Composite Video Signal Output Levels (internally generated levels) Metal Option
No. 5039-18/19
Output
level
Output
voltage
(VDC)
Character
level
1
3.342
Character
level
2
3.153
Background
high
level
2
2.950
Background
high
level
1
2.735
Burst
high
level
2.436
Frame
level
2
2.312
Output
level
Output
voltage
(VDC)
Frame
level
1
2.166
Pedestal
level
2.118
Background
low
level
1
1.902
Burst
low
level
1.770
Sync
level
1.500
