No. 5213-5/16
LC74725, 74725M
Note: CPDT goes to the high-impedance state when CS2 is high.
Figure 2 EDS Serial Output Test Conditions (N-Channel Open-Drain Circuit)
Note: The O/E signal is output from the SYNCJDG pin when SEL0 is high.
LN21 outputs the even field when MOD0 is low, and both fields when MOD0 is high.
Figure 3 O/E and LN21 Output Timing
