LB11947
No.7318-4/14
* Note 4 : Measurement of through current
Measure the current flowing to pin E during phase switching of “H”
→ “L” and “L” → “H” after its conversion to the
voltage with a detection resistor.
The current exceeding the current value of 1A at the pulse width of 500ns or more is judged to be NG as the through
current.
Package Dimensions
unit : mm (typ)
3147C
SANYO : DIP28H(500mil)
1
14
28
15
0.4
0.6
4.0
26.75
20.0
R1.7
8.4
(1.81)
1.78
1.0
12.7
11.2
PHASE
Pin E
1A
500ns
Pd max -- Ta
Ambient temperature, Ta – °C
Allowable
power
dissipation,
Pd
max
–
W
0
2
3
1.5
2.5
1
0.5
3.5
– 20
80 85
1.56
60
20
40
0
100
Independent IC
