參數資料
| 型號： | LA4425PV-MPB-H |
| 廠商： | ON Semiconductor |
| 文件頁數： | 1/8頁 |
| 文件大小： | 0K |
| 描述： | IC AUDIO POWER AMP 5W 44SSOP |
| 標準包裝： | 30 |
| 類型： | AB 類 |
| 輸出類型： | 1-通道（單聲道） |
| 在某負載時最大輸出功率 x 通道數量： | 6W x 1 @ 4 歐姆 |
| 電源電壓： | 5 V ~ 16 V |
| 特點： | 消除爆音，過壓保護，短路保護，熱保護 |
| 安裝類型： | * |
| 供應商設備封裝： | * |
| 封裝/外殼： | * |
| 包裝： | * |
31412 SY/22912 SY 20110916 S00002 No.A2011-1/8
http://onsemi.com
Semiconductor Components Industries, LLC, 2013
June, 2013
LA4425PV
Overview
The LA4425PV is a 5W power amplifier with very few external parts. Encapsulated in a surface mount package
[SSOP44K (275 mil)], it is designed for operation without a heat sink. Only two external parts (Only IN/OUT coupling
capacitors). Almost no evaluation, adjustment and check of its functions as a power IC required, enabling control to be
simplified and set patterns to be further miniaturized.
Functions
Wide operation supply range → 5 to 16V
On-chip protection:
- Over-voltage protection
- Thermal protection
- Output D.C. short protection .
On-chip pop noise reducing circuit
Specifications
Maximum Ratings at Ta = 25
°C
Parameter
Symbol
Conditions
Ratings
Unit
Maximum supply voltage
VCC max
Rg = 0
Ω
18
V
Surge maximum supply voltage
VCC surge
Giant pulse 200ms
Rise time 1ms
50
V
Maximum output current
IO peak
3.3
A
Allowable power dissipation
Pd max
When mounted on the specified PCB
5.15
W
Operating temperature
Topr
-40 to +85
°C
Storage temperature
Tstg
-40 to +150
°C
Ordering number : ENA2011A
Monolithic Linear IC
5W Power Amplifier
with Very Few External Parts
for Car Radio and Car Stereo
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the Recommended Operating
Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability.
