KP110
Data Book
11
2003-05
Accuracy
Accuracy is the deviation in actual output from nominal output over the entire pressure
and temperature range according to figure below due to all sources of error including the
following:
Pressure:
Output deviation from target transfer function over the specified pressure range.
Temperature:
Output deviation over the temperature range.
Aging during operating time
The error band is determined by a continuous line through four relevant break points:
Note: The gained output signal accuracy depends largely on the quality of the mounting
and calibration process accomplished by the customer!
Figure 5
Overall Accuracy over Temperature
Break Point (°C)
– 40
10
85
140
Typical Accuracy (kPa)
± 2.4
± 1.2
± 1.2
± 2.4
