- 您現在的位置：買賣IC網 > PDF目錄373106 > KBP005 (上海朗碩科技有限公司) SINGLE PHASE GLASS BRIDGE RECTIFIER PDF資料下載
參數資料
| 型號： | KBP005 |
| 廠商： | 上海朗碩科技有限公司 |
| 元件分類： | 參考電壓二極管 |
| 英文描述： | SINGLE PHASE GLASS BRIDGE RECTIFIER |
| 中文描述： | 玻璃單相橋式整流器 |
| 文件頁數： | 1/2頁 |
| 文件大?。?/td> | 48K |
| 代理商： | KBP005 |
Symbols
KBP005
KBP01
KBP02
KBP04
KBP06
KBP08
KBP10
Units
Maximum repetitive peak reverse voltage
V
RRM
50
100
200
400
600
800
1000
Volts
Maximum RMS bridge input voltage
V
RMS
35
70
140
280
420
560
700
Volts
Maximum DC blocking voltage
V
DC
50
100
200
400
600
800
1000
Volts
Maximum average forward rectified output current
at T
A
=50
I
(AV)
2.0
Amps
Peak forward surge current, 8.3mS single
half sine-wave superimposed on rated load
I
FSM
50.0
Amps
Maximum forward Voltage drop per bridge element
at 1.0A peak
V
F
1.0
Volt
Maximum DC reverse current at rated
DC blocking voltage per element
I
R
10.0
A
Maximum DC reverse current at rated
DC blocking voltage per element T
A
=100
I
R
1.0
mA
Operating temperature range
T
J
-55 to +125
Storage temperature range
T
STG
-55 to +150
Features
KBP005 THRU KBP10
SINGLE-PHASE SILICON BRIDGE
Reverse Voltage -
50 to 1000 Volts
Forward Current -
2.0 Amperes
Surge overload rating - 50 amperes peak
Ideal for printed circuit board
Plastic material has Underwriters Laboratory
Flammability Classification 94V-0
Mounting Position: Any
Lead: Silver plated copper lead
Maximum Ratings and Electrical Characteristics
Ratings at 25
For capacitive load, derate current by 20%.
ambient temperature unless otherwise specified. Resistive or inductive load, 60Hz.
1
DIM ENSIONS
DIM
inches
m m
Note
M in.
M ax.
M in.
M ax.
A
-
0.504
-
12.8
B
0.75
-
19.0
-
C
-
0.693
-
17.6
D
-
0.25
-
6.4
E
-
0.125
-
3.2
F
-
0.15
-
3.8
G
0.32 Typ.
0.8 Typ.
