Features
Superminiature, High power.
Low coil power consumption.
PC board mounting.
Suitable for household appliance, automation system, electronic equipment, instrument and meter, communication
facilities and remote control facilities.
Ordering Information
NT73 C S 10 DC12V F
1 2 3 4 5 6
1 Part number
：
NT73
（
JQC-3FC
）
2 Contact arrangement
：
A:1A
；
B:1B
；
C:1C
3 Enclosure
：
S: Sealed type
4 Contact Current
：
5:5A
；
6:6A
；
10:10A
；
12:12A
5 Coil rated Voltage(V)
：
DC:3,4.5,5,6,9,12,24,36,48
6 Resistance Heat Class
：
NIL:130
℃；
F:155
℃
Contact Data
Contact Arrangement
Contact Material
Contact Rating (resistive)
Max. Switching Power
Max. Switching Voltage
Contact Resistance or Voltage drop
Electrical
Operation
life
Mechanical
Coil Parameter
1A
Ag CdO Ag SnO
5A,6A,10A,12A/125VAC,28VDC; 6A/277VAC; 5A,10A/250VAC
336W 2500VA
110VDC 380VAC Max. Switching Current:12A
100m
Item 3.12 of IEC255-7
10
5
Item 3.30 of IEC255-7
10
7
Item 3.31 of IEC255-7
SPSTNO
1B
SPSTNC
1C
SPDT(B-M)
Coil voltage
VDC
Dash
numbers
Rated
Max.
Coil
resistance
±
10%
Pickup
voltage
VDC(max)
(75%of rated
voltage )
release voltage
VDC(min)
(10% of rated
voltage)
Coil power
consumption
W
Operate
Time
ms
Release
Time
ms
003-360
004-360
005-360
006-360
009-360
012-360
024-360
028-360
036-360
048-360
3
3.9
5.9
6.5
7.8
11.7
15.6
31.2
36.4
46.8
62.4
25
65
69
100
225
400
1600
2180
3600
6400
2.25
3.4
3.75
4.50
6.75
9.00
18.0
21.0
27.0
36.0
0.3
0.45
0.5
0.6
0.9
1.2
2.4
2.8
3.6
4.8
4.5
5
6
9
12
24
28
36
48
0.36
10
5
CAUTION
:
1.The use of any coil voltage less than the rated coil voltage will compromise the operation of the relay.
2.Pickup and release voltage are for test purposes only and are not to be used as design criteria.
79
19.5
×
16.5
×
16.5
