HFW1131L01P Product Details
HFW1131L01P
(4-1617029-1)
T E I nternal N umber: 4 -1 6 1 7 0 2 9 -1
Military/Aerospace High Performance Relays
Product Highlights:
l
HFW Half-Size Relay Series
l
Input Voltage = 5 VDC
l
Contact Arrangement = 2 Form C, DPDT, 2 C/O
l
Contact Current Rating = 2 Amps.
l
Non Polarized, Monostable Coil Magnetic System
Quick Links
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
RELAY (PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Termination Type = Solder Hook Terminals
Electrical Characteristics:
l
Input Voltage (VDC) = 5
l
Contact Current Rating (Amps.) = 2
l
Coil Polarity Protection Diode = Without
l
Transistor Driver = Without
l
Coil Resistance (?) = 27
l
MOSFET Driver = Without
l
Coil Power Measurement = Milliwatts
l
Coil Power, Nominal (mW) = 926
l
Actuating System = DC
l
Shock = 100G's, 6ms
l
Vibration = 30G's, 10 to 3000Hz
Body Related Features:
l
Series = HFW Half-Size Relay
Contact Related Features:
l
Mounting Options = Panel Mount
l
Enclosure = Hermetically Sealed
l
Approved Standards = M39016 Qualified, P Level
Configuration Related Features:
l
Contact Arrangement = 2 Form C, DPDT, 2 C/O
l
Coil Magnetic System = Non Polarized, Monostable
l
Coil Suppression Diode = Without
Industry Standards:
l
Government/Industry Qualification = Yes
l
Government/Industry Part Number = M39016/6-135P
l
RoHS/ELV Compliance = Not ELV/RoHS compliant
l
Lead Free Solder Processes = Not suitable for lead free processing
Conditions for Usage:
l
Temperature Range (?C) = -65 – +125
Other:
l
Brand = CII
Corporate Information
Quick Links
Customer Support
Search by Keyword or Part #
