- 您現在的位置：買賣IC網 > PDF目錄60615 > GSC2128 (GTM CORPORATION) CMOS LOW DROPOUT VOLTAGE REGULATOR PDF資料下載
參數資料
| 型號： | GSC2128 |
| 廠商： | GTM CORPORATION |
| 元件分類： | 線性穩壓 |
| 英文描述： | CMOS LOW DROPOUT VOLTAGE REGULATOR |
| 中文描述： | CMOS低壓降穩壓器 |
| 文件頁數： | 1/6頁 |
| 文件大?。?/td> | 592K |
| 代理商： | GSC2128 |
1/6
ISSUED DATE :2005/06/21
REVISED DATE :2005/10/04B
G
G S
S C
C 22112288
C
C M
M O
O S
S L
L o
o w
w D
D rr o
o p
p o
o u
u tt V
V o
o ll tt aa g
g ee R
R ee g
g u
u ll aa tt o
o rr
Description
The GSC2128 series of positive, linear regulators feature low quiescent current (45 A typ.) with low dropout
voltage, making them ideal for battery applications.
Output voltages are set at the factory and trimmed to 1.5% accuracy.
These rugged devices have both Thermal Shutdown, and Current Fold-back to prevent device failure under
the “Worst” of operating conditions.
In applications requiring a low noise, regulated supply, place a 1000pF capacitor between Bypass and Ground.
The GSC2128 is stable with an output capacitance of 4.7 F or greater.
Features
Functional Block Diagram
&Very Low Dropout Voltage
&Guaranteed 1.5A output
&Over-Temperature Shutdown
&Current Limiting
&Short Circuit Current Fold-back
&Highly Accurate± 1.5%
&Low Temperature Coefficient
&Noise Reduction Bypass Capacitor
&Power-Saving Shutdown Mode
Applications
&Battery Powered Widgets
&Instrumentation
&Wireless Devices
&PC Peripherals
&Portable Electronics
Package Dimensions
Millimeter
REF.
Min.
Max.
REF.
Min.
Max.
A
5.80
6.20
M
0.10
0.25
B
4.80
5.00
H
0.35
0.49
C
3.80
4.00
L
1.35
1.75
D
0 C
8 C
J
0.375 REF.
E
0.40
0.90
K
45 C
F
0.19
0.25
G
1.27 TYP.
Typical Application Circuit
