FTLF8528P2BCV Pluggable SFP+ Product Specification – November 2007
Finisar Corporation November 21, 2007 Rev. B
Page 5
IV.
Optical Characteristics (TA = -5 to 70 °C, VCC = 3. 0 to 3.6 Volts)
Parameter
Symbol
Min
Typ
Max
Unit
Ref.
Transmitter
Output Opt. Pwr: 50 or 62.5 MMF
POUT
-9
-2
dBm
1
Optical Wavelength
λ
830
860
nm
Spectral Width
σ
0.65
nm
Optical Modulation Amplitude @ 2.125 Gb/s
OMA
196
μW
2
Optical Modulation Amplitude @ 4.25 Gb/s
OMA
247
μW
2
Optical Modulation Amplitude @ 8.5 Gb/s
OMA
302
μW
2
Optical Rise/Fall Time @ 2.125, 4.25 Gb/s
tr/ tf
90
ps
3
Transmitter Waveform and Dispersion Penalty
@ 8.5 Gb/s
TWDP
4.2
dB
4
Relative Intensity Noise
RIN
-128
dB/Hz
Deterministic Jitter Contribution @ 2.125 Gb/s
TX
Δ DJ
56.5
ps
Total Jitter Contribution @ 2.125 Gb/s
TX
Δ TJ
119.6
ps
5
Deterministic Jitter Contribution @ 4.25 Gb/s
TX
Δ DJ
28.2
ps
Total Jitter Contribution @ 4.25 Gb/s
TX
Δ TJ
59.8
ps
5
Receiver
Receiver OMA Sensitivity = 2.125 Gb/s
RxSENS
49
μW
Receiver OMA Sensitivity = 4.25 Gb/s
RxSENS
61
μW
Receiver OMA Sensitivity = 8.5 Gb/s
RxSENS
76
μW
Average Receiver Power
RxMAX
0
dBm
Optical Center Wavelength
λ
C
770
860
nm
Optical Return Loss
12
dB
LOS De-Assert
LOSD
-18
dBm
LOS Assert
LOSA
-30
dBm
LOS Hysteresis
0.5
dB
Notes:
1.
Class 1 Laser Safety per FDA/CDRH, and EN (IEC) 60825 laser safety standards.
2.
Equivalent extinction ratio specification for Fibre Channel. Allows smaller ER at higher average
power.
3.
Unfiltered, 20-80%. Complies with FC 1x and 2x eye mask when filtered.
4.
TWDP is calculated with a 1.0 equalizer and a 6,860 MHz Gaussian filter for the fiber simulation.
Jitter values at
γ
T and γR are controlled by TWDP and stress receiver sensitivity.
5.
If measured with TJ-free data input signal. In actual application, output TJ will be given by:
() (
)2
2
DJ
TJ
DJ
TJ
DJ
TJ
IN
OUT
Δ
Δ
+
+
Δ
+
=
