Finisar Corporation Jun 25, 2009 Rev.J
Page 1
Product Specification
4.25 Gb/s RoHS Compliant Short-Wavelength SFP Transceiver
FTLF8524P2xNy
PRODUCT FEATURES
Up to 4.25 Gb/s bi-directional
data links
Hot-pluggable SFP footprint
Built-in digital diagnostic functions
850nm Oxide VCSEL laser
transmitter
Duplex LC connector
RoHS Compliant and Lead Free
Up to 500m on 50/125
μm MMF,
300m on 62.5/125
μm MMF
Metal enclosure, for lower EMI
Single 3.3V power supply
Extended operating temperature
range: -20°C to 85°C
APPLICATIONS
Tri-Rate 1.063/2.125/4.25 Gb/s
Fibre Channel
1.25 Gb/s 1000Base-SX Ethernet
(Rate selectable version)
Wireless – OBSAI, CPRI
Finisar’s FTLF8524P2xNy Small Form Factor Pluggable (SFP) transceivers are
compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA)
1.
They are compatible with Fibre Channel FC-PI-2 Rev. 7.0
2. Rate Selectable versions are
also compatible with Gigabit Ethernet as specified in IEEE Std 802.3
3. They are RoHS
compliant and lead-free per Directive 2002/95/EC
4 and Finisar Application Note AN-
2038. Digital diagnostics functions are available via the 2-wire serial bus specified in the
SFP MSA.
PRODUCT SELECTION
FTLF8524P2xNy
x
W
Wide Extraction Bail
B
Narrow Extraction Bail
y
L
Non Rate Selectable - 1x, 2x, 4x Fibre Channel
V
Rate Selectable - 1x, 2x, 4x Fibre Channel and Gigabit Ethernet
