參數資料
型號： FQD6N60C
廠商： Fairchild Semiconductor Corporation
英文描述： 600V N-Channel MOSFET
中文描述： 600V的N溝道MOSFET
文件頁數： 1/8頁
文件大?。?/td> 678K
代理商： FQD6N60C
2005 Fairchild Semiconductor Corporation
FQD6N60C Rev. A
1
www.fairchildsemi.com
F
QFET
FQD6N60C
600V N-Channel MOSFET
Features
4 A, 600 V, R
DS(on)
= 2.0
@ V
GS
= 10 V
Low gate charge ( typical 16 nC )
Low Crss ( typical 7 pF)
Fast switching
100 % avalanche tested
Improved dv/dt capability
Description
These N-Channel enhancement mode power field effect
transistors are produced using Fairchild’s proprietary, planar
stripe, DMOS technology.
This advanced technology has been especially tailored to
minimize on-state resistance, provide superior switching
performance, and withstand high energy pulse in the avalanche
and commutation mode. These devices are well suited for high
efficiency switched mode power supplies, active power factor
correction, electronic lamp ballasts based on half bridge
topology.
Absolute Maximum Ratings
Thermal Characteristics
●
●
●
●
●
●
▲
!
!
S
!
!
!
!
D
G
D-PAK
FQD Series
G
S
D
Symbol
Parameter
FQD6N60C
Units
V
DSS
I
D
Drain-Source Voltage
600
V
Drain Current
- Continuous (T
C
= 25°C)
- Continuous (T
C
= 100°C)
- Pulsed
4
A
2.4
A
I
DM
V
GSS
E
AS
I
AR
E
AR
dv/dt
Drain Current
(Note 1)
16
A
Gate-Source Voltage
±
30
V
Single Pulsed Avalanche Energy
(Note 2)
300
mJ
Avalanche Current
(Note 1)
4.0
A
Repetitive Avalanche Energy
(Note 1)
8.0
mJ
Peak Diode Recovery dv/dt
(Note 3)
4.5
V/ns
P
D
Power Dissipation (T
C
= 25°C)
80
W
- Derate above 25°C
0.78
W/°C
T
J
, T
STG
T
L
Operating and Storage Temperature Range
-55 to +150
°C
Maximum lead temperature for soldering purposes,
1/8
"
from case for 5 seconds
300
°C
Symbol
Parameter
Typ
Max
Units
R
θ
JC
R
θ
JA
R
θ
JA
* When mounted on the minimum pad size recommended (PCB Mount)
Thermal Resistance, Junction-to-Case
--
1.56
°C
/
W
Thermal Resistance, Junction-to-Ambient *
--
50
°C
/
W
Thermal Resistance, Junction-to-Ambient
--
110
°C
/
W
