12
REV. 1I July 2005
DATA SHEET
FMS6407
Filter Settings
Table I
F
SEL1
, Pin 10
0
0
1
1
F
SEL0
, Pin 9
0
1
0
1
Filter -3dB Freq
8.2MHz
15MHz
32MHz
Filter Bypass
Video Format
SD, 480i
PS, 480p
HD, 1080i, 720p
–
Sync Format
Bi-level, 4.7
μ
s pulse width
Bi-level, 2.35
μ
s pulse width
Tri-level, 589ns pulse width
Bi-level, 2.35
μ
s pulse width
Format
480i
480p
720p
1080i
Refresh
30Hz
60Hz
60Hz
30Hz
Sample Rate
13.5MHz
27MHz
74.25MHz
74.25MHz
Period (T)
74ns
37ns
13.4ns
13.4ns
A
B
C
H-Rate
15.75kHz
31.5kHz
45kHz
33.75kHz
20T = 1.5
μ
s
20T = 750ns
70T = 938ns
44T = 589ns
64T = 4.7
μ
s
64T = 2.35
μ
s
40T = 536ns
44T = 589ns
61T = 4.5
μ
s
61T = 2.25
μ
s
220T = 2.95
μ
s
148T = 1.98
μ
s
Note:
Timing values are approximate for 30Hz/60Hz refresh rates.
Application Information
Input Circuitry
The DC restore circuit in the FMS6407 requires a source
impedance (R
source
= R
s
|| R
T
) of less than or equal to 150
for correct operation.
Driving the FMS6407 with a high-
impedance source (e.g. a DAC loaded with 330
) will not
yield optimum results.
Output Drive
The FMS6407 is specified to operate with output currents
typically less than 60mA, more than sufficient for a dual
(75
) video load. Internal amplifiers are current limited to
approximately 100mA and should withstand brief duration
short circuit conditions, however this capability is not
guaranteed.
The maximum specified input voltage of 1.5V
pp
can be sus-
tained for all inputs. When the input is clamped to 1.125V,
this does not result in a meaningful output signal. With a
gain of 6dB, the output should be 1.125V ±1.5V which is not
possible since the output cannot drive below ground. This
condition will not damage the part; however, the output will
be clipped. For signals which are clamped to 250mV, this
does not occur.
Signals that are at midscale during SYNC (Pb, Pr, C) must
be clamped to 1.125V and signals that are at their lowest
during SYNC (Y, CV, R, G, B) must be clamped to 250mV
for proper operation. Clamping a CV signal to 1.125V will
result in clipping the top of the signal and clamping a Pr sig-
nal to 250mV will result in clipping the bottom of the signal.
The 220
μ
F capacitor coupled with the 150
termination, as
shown in the Typical Application Circuit of Figure 5, forms a
high pass filter that blocks the DC while passing the video
frequencies and avoiding tilt. Any value lower than 220
μ
F
will create problems, such as video tilt. Higher values, such
as 470
μ
F - 1000
μ
F are the most optimal output coupling
capacitor. By AC coupling, the average DC level is zero.
Thus, the output voltages of all channels will be centered
around zero.
Sync Recovery
The FMS6407 will typically recover bi-level sync with
amplitude greater than 100mV (33% compressed relative to
the nominal 300mV amplitude). The FMS6407 looks for the
lowest signal voltage and clamps this to approximately
250mV at the output.
Tri-level sync may not be compressed more than 5% (15mV)
for correct operation. Tri-level sync is located by finding the
edges of the tri-level pulse and running a timer to operate the
clamp during the back porch interval.
Since only the Y/G channel is processed for sync recovery, Y
and CV inputs must be synchronous.
