7
230R Series (Conforms to SCSI)
Dimensions are in millimeters (inches)
www.fcai.fujitsu.com
Specifications
subject to change
RIGHT-ANGLE SOCKET (SCREW LOCK TYPE)
s DIMENSIONS
Unit: mm (in.)
s MOUNTING HOLE LAYOUT (COMPONENT SIDE)
57.91 ±0.1 (2.279 ±0.004)
41.73 ±0.1 (1.642 ±0.004)
Position of pin 2
Position of pin 1
3.5
mm
(0.138
in.)
max.
Thickness of board : t = 1.6 mm (0.063 in.)
2-
φ
3.0
(2-
φ
0.118
)
1.905
±0.1
(0.075
±0.004
)
1.27 ±0.1 (0.050 ±0.004)
φ0.8 ±0.06
(
φ.031 ±0.002)
Unit: mm (in.)
s PATTERN INHIBITED AREAS
s RECOMMENDED PANEL DIMENSIONS
Unit: mm (in.)
54.21 ±0.1 (2.134±0.004)
57.91 ±0.1 (2.279±0.004)
Thickness of recommended panel: t = 1.5 mm (0.059 in.)
7.5
±0.1
(0.295
±0.004
)
R 2.2 ±0.1
(R 0.086±0.004)
57.91 ±0.1 (2.279 ±0.004 )
3.5
mm
(0.138
in.)
max.
6.8 –0
(0.267 –0)
3.2 –0
(0.125 –0)
6
–0
(0.023
–0
)
3.2
–0
(0.125
–0
)
1.905
±0.1
(.075
±0.004
)
s PART NUMBER
FCN-235D068-G/EA
s NUMBER OF CONTACTS
68 contacts
Note: Remove the spacer to mount the connector
on the panel, then tighten the hexagon nuts.
Make sure that the panel is sandwiched
between the connector and nuts.
63.88 (2.514)
57.91 (2.279)
41.91 (1.633)
46.08 (1.814)
2-No. 2-56UNC
No. 1
2-No. 2-56UNC
10.50
(0.413)
0.40
(0.015)
1.27(0.050)
5.5
(0.216)
12.30
(0.484)
4.70
(0.185)
4.37
(0.173)
1.905
(0.075)
5
(0.196)
0.40
(0.015)
5.51
(0.216)
3.4
(0.133)
0.70
(0.027)
6.605
(0.260)
