Copyright Cirrus Logic, Inc. 2011
(All Rights Reserved)
DS507F2
EP7309
High-Performance, Low-Power System on Chip
Processor Core - ARM720T
The
EP7309
incorporates
an
ARM
32-bit
RISC
microcontroller that controls a wide range of on-chip
peripherals. The processor utilizes a three-stage pipeline
consisting of fetch, decode and execute stages. Key features
include:
ARM (32-bit) and Thumb (16-bit compressed) instruction
sets
Enhanced MMU for Microsoft Windows CE and other
operating systems
8 KB of 4-way set-associative cache.
Translation Look Aside Buffers with 64 Translated Entries
Power Management
The EP7309 is designed for ultra-low-power operation. Its core
operates at only 2.5 V, while its I/O has an operation range of
2.5 V–3.3 V allowing the device to achieve a performance
level equivalent to 60 MIPS. The device has three basic power
states:
Operating — This state is the full performance state.
All the clocks and peripheral logic are enabled.
Idle — This state is the same as the Operating State,
except the CPU clock is halted while waiting for an
event such as a key press.
Standby — This state is equivalent to the computer
being switched off (no display), and the main
oscillator shut down. An event such as a key press
can wake-up the processor.
MaverickKey Unique ID
MaverickKey unique hardware programmed IDs are a solution
to the growing concern over secure web content and
commerce. With Internet security playing an important role in
the delivery of digital media such as books or music,
traditional software methods are quickly becoming unreliable.
The MaverickKey unique IDs provide OEMs with a method of
utilizing specific hardware IDs such as those assigned for
SDMI (Secure Digital Music Initiative) or any other
authentication mechanism.
Both a specific 32-bit ID as well as a 128-bit random ID is
programmed into the EP7309 through the use of laser probing
technology. These IDs can then be used to match secure
copyrighted content with the ID of the target device the
EP7309 is powering, and then deliver the copyrighted
information over a secure connection. In addition, secure
transactions can benefit by also matching device IDs to server
IDs. MaverickKey IDs provide a level of hardware security
required for today’s Internet appliances.
Memory Interfaces
The EP7309 is equiped with a ROM/SRAM/FLASH-style
interface that has programmable wait-state timings and
includes burst-mode capability, with six chip selects decoding
six 256 MB sections of addressable space. For maximum
flexibility, each bank can be specified to be 8-, 16-, or 32-bits
wide. This allows the use of 8-bit-wide boot ROM options to
minimize overall system cost. The on-chip boot ROM can be
used in product manufacturing to serially download system
code into system FLASH memory. To further minimize system
memory requirements and cost, the ARM Thumb instruction
set is supported, providing for the use of high-speed 32-bit
operations in 16-bit op-codes and yielding industry-leading
code density.
Digital Audio Capability
The EP7309 uses its powerful 32-bit RISC processing engine
to implement audio decompression algorithms in software. The
nature of the on-board RISC processor, and the availability of
efficient C-compilers and other software development tools,
ensures that a wide range of audio decompression algorithms
can easily be ported to and run on the EP7309
Universal Asynchronous
Receiver/Transmitters (UARTs)
The EP7309 includes two 16550-type UARTs for RS-232
serial communications, both of which have two 16-byte FIFOs
for receiving and transmitting data. The UARTs support bit
Pin Mnemonic
I/O
Pin Description
BATOK
I
Battery ok input
nEXTPWR
I
External power supply sense
input
nPWRFL
I
Power fail sense input
nBATCHG
I
Battery changed sense input
Table 1. Power Management Pin Assignments
Pin Mnemonic
I/O
Pin Description
nCS[5:0]
O
Chip select out
A[27:0]
O
Address output
D[31:0]
I/O
Data I/O
nMOE
O
ROM expansion OP enable
nMWE
O
ROM expansion write enable
HALFWORD
O
Halfword access select
output
WORD
O
Word access select output
WRITE
O
Transfer direction
Table 2. Static Memory Interface Pin Assignments
