DS2720
21 of 21
EEPROM RELIABILITY
SPECIFICATION:
(-20
°C to +70°C, 2.5V VDD 5.5V)
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
NOTES
Copy to EEPROM Time
tEEC
1
5
ms
EEPROM Copy Endurance
NEEC
25,000
cycles
EEPROM Data Retention
tEEDR
4
years
NOTES
1. All voltages are referenced to VSS.
2. Specified with no resistive load on CC, DC, or CP.
3. Contact the factory for different voltage trip points and delay periods.
4. Typical load capacitance on CC, DC is 1000pF CP (charge pump reservoir cap) = 0.1
mF. DC load
total on CC, DC, CP > 10M
W.
5. RTST = |VPLS - VDD| / I measured, with VPLS = 3.2V, VDD = 3.6V when test current, ITST, active for
RTST1 ; and VPLS = 4.0V, VDD = 2.5V when recovery charging for RTST2.
6. Maximum high-to-low fall time is 5
ms.
7. Internal 10V clamp on DC pin limits DC output logic low when PLS > 10V
8. Short-circuit delay tested with VDD ramped from 3.1V to 1.9V in 5
ms. Delay measured from VDD =
2.5V to DC pin fall to 7V from VOHCP.
