173
D
DA-3380
DVD-RAM MASTERING GENERATOR
D
RF-1st signal (embossed area output) and RF-2nd signal
(rewritable area output)
Output range(TOP)
Variable at 0 ~ Approx.+1.0V
Output range(BOTOM)
Variable at 0 ~ TOP level
Setting resolution
2mV
Output impedance
Approx. 50
Transmission clock
FR-1st : 5.22MHz(450 rpm)
RF-2nd:
5.50MHz ~ 12.94MHz (450 rpm)
Frequency accuracy
20ppm or less
Residual jitter
1ns or less
Rise time and fall time
5ns or less
Pulse width variable function
Setting range
Approx.-1T ~ Approx.+20ns
Setting resolution
2ns
Automatic switch at output level
Switch by each T
3T ~ 14T
Deflect signal (groove signal + header position control signal)
Groove signal
Output range
Variable at 0 ~ Approx.200mV Sine wave
Setting resolution
1 mV
Output impedance
Approx.50
Output frequency
29.58kHz ~ 69.57kHz(450rpm)
Frequency accuracy
20ppm or less
Distortion rate
1% or less(20mV ~ 200mVp-p)
Groove end position correction
Variable range :
3T ~ 7T(Standard value 5T)
Setting resolution :
Output polarity switch
output polarity is reversed
Header position control signal
Output range
Variable at 0 ~ Approx. ± 500mV, pulse signal
Setting resolution
2mV (Possible to set positive and
negative individually)
Rise time and fall time
20ns or less
Output position adjustment (ID1,2) :
0 ~ + 4T in end position of groove, 0.5T step
Output position adjustment(ID3,4) :
0 ~ + 4T in end mark of ID2, 0.5T step
START/STOP signal (input)
Input impedance
Approx.47 k
Proper pulse width
10ms or less
Logical polarity
Active low
LOCK signal (output)
Output
Line driver signal (pulse signal)
Output impedance
Approx.50
Output frequency
15.75kHz
Frequency accuracy
20ppm or less
Duty ratio
50±10%
Power source
100 ~ 240 VAC, 50/60 Hz
Approx.16 W
Case dimensions
190 (W)
×
128 (H)
×
350 (D)mm
(projections not included)
Weight
Approx. 3.6 kg
0.5T
Dual beam drive
It is necessary to drive two laser spots to record the data in the
embossed data area and rewritable area.
LOCK signal
The rotation control function of CAV is necessary follow the
reference signal from the unit.
START signal
Beginning of the signal generation is detected from the radius
position of the disc and the function to output the beginning
timing to the unit is necessary.
REQUIREMENT FOR OPTICAL CUTTER
SPECIFICATIONS
