SMD Power Inductors - Shielded
ctparts.com
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322 Inside US
949-453-1811 Outside US
Copyright 2008 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
CENTRAL Technologies
07.15.08
SPECIFICATIONS
Part numbers indicate tolerance available.
M = ±20%, N = ±30%
L Test
DCR
IDC
Part
Inductance
Freq.
Max.
Number
(H)
(kHz)
(
Ω
Ω)
(A)
CTEPH149F-R56N
0.56
100
0.0010
30
CTEPH149F-1R0M
1.00
100
0.00135
22
CTEPH149F-1R6M
1.60
100
0.0017
18
CTEPH149F-2R2M
2.20
100
0.00235
15
CTEPH149F-2R4M
2.40
100
0.00235
15
CTEPH149F Series
From 0.56 H to 2.4 H
Not shown at actual size.
CHARACTERISTICS
Description: SMD shielded power inductor (Ultra High Current)
Applications: Excellent for power line DC-DC conversion
applications used in notebook computers and other handheld
electronic equipment
Operating Temperature: -40°C to +85°C
Storage Temperature: -40°C to +125°C
Temperature rise: 40°C Typical at IDC
Resistance to solder heat: 260°C for 10 seconds
Rated Current: Based on temperature &
ΔL / L0A =25% Typ. at
IDC
Inductance Tolerance: ±20%, ±30%
Testing: Tested on a HP4285A at 100 KHz , 1V
Packaging: Tape & Reel
Marking: Parts are marked with inductance code
Miscellaneous: RoHS Compliant.
Additional Information: Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PAD LAYOUT
13.5
5.0
Unit: mm
3.0
XXX
Marking
A
C
B
E
Inductance Code
D
H
G
D1
F
1
3
2
1
3
2
Size
A
B
C
D
D1
E
F
G
H
mm 14.7±0.3 15.0±0.3
9.5±0.3
4.0±0.3
2.0±0.3
8.0±0.3
4.0±1.0
2.2±0.3
1.2±0.2
inches 0.58±0.01 0.59±0.01 0.37±0.01 0.16±0.01 0.08±0.01 0.31±0.01 0.16±0.04 0.09±0.01 0.05±0.008
PHYSICAL DIMENSIONS
RoHS
Compliant
