2012ProductSummary|AudioComponents7
6
For more information, visit www.cirrus.com
Audio DSP Tools
Features
DSP Composer
DSPComposerTMisagraphicaltoolsupportingdrag-and-dropdesignofcustomaudiosignalflows.Usersofthistoolcancreate
customaudioprocessingfirmwareforanyoftheDSPICFamilieswithoutwritingcustomDSPcode,bycombiningchoicesfroma
largeselectionofexistingaudioprocessingprimitiveelements.DSPComposeralsoprovidesrun-timecontroloffirmware
parameters,bothforcustomprocessingblocksandforCirrusLogicsuppliedprocessingblocks.
CLIDE
TheCirrusLogicIntegratedDevelopmentEnvironment(CLIDETM)isanEclipse-basedworkbenchsupportingdevelopmentof
customcodeforCirrusLogicDSPs.CLIDEencapsulatesmanyoftheotheravailableprogrammingtools,including:assembler;
linker;Ccompiler;debugger;andsimulator.CLIDEalsoincludesasetofwizardstoaidinthecreationofdifferentformsofDSP
projects,suchascustomULDsandcustomComposerprimitives.
DSP Condenser
DSPCondenserTMisasetoftoolsandamethodologytosupportcreationofacomplexAVRorsoundbarapplicationusingCirrus
Logicmulti-coreDSPs.ThetoolsetincludestoolsfordefiningthefirmwareandconfigurationsettingsforallDSPfirmwaretobe
supportedbytheapplication,plussamplemicrocode(writteninC)forcontrollingtheDSP.TheDSPCondensertoolset
"condenses"theoutputofmultipleDSPComposerprojectsintoasingleflashimagethatisthenmanagedbytheDSPoperating
system(OS).
Micro Condenser
MicroCondenserTMisasetoftoolsandamethodologytosupportcreationofflashimagecontainingfirmwareandconfiguration
settingsforasingle-coreormulti-coreDSP.Thetoolsetincludessamplemicrocode(writteninC)forcontrollingtheDSP.
C Compiler
TheCirrusCCompiler(CCC)isanISO-compliantCcompilerwithISO-recommendedenhancementsforsupportingDSP
architectures,including:supportforfixedpointarithmetictypes;andsupportforseparatememoryspaces.
CDB-MCU-DEBUG Board
TheCDB-MCU-DEBUGRevBboardisaUSBbaseddebuginterfacethatenablesacustomertodebug/tunetheendproduct
usingtheCirrusLogictoolssuchasCLIDEandDSPComposer.
CobraNet System Modules
Product
Description
CobraNet
Part Numbers
Audio Channels
over Ethernet
(full-duplex)
Serial Input/
Output Ports
Ethernet
Interface
Integrated
DSP (MIPS)
Board
Dimensions
CM-1
Digitalaudio
networkinterface
modulewithdual
Ethernetports
SeeyourCirrus
Logicsales
representativefor
availablemodels.
32
Quadsynchronous,upto32
channelsat48and/orupto
96kHzsamplerates
100BASE-Tx,
100Mbps,fullduplex
Ethernet,fully
compliantwithIEEE
802.3u
—
3.5"X3.5"
CM-2
Digitalaudio
networkinterface
modulewithdual
Ethernetportsand
audioDSP(available
asareference
design)
CPB181012-CM2,
CPB181022-CM2,
CPB496122-CM2,
(allavailablewith
female-bottomor
male-topheaders)
16
Quadsynchronous,capable
ofsupplyingupto16
full-duplexchannelsat48
kHzsamplerateorupto8
full-duplexchannelsat96
kHzsamplerate
100BASE-Tx,
100Mbps,fullduplex
Ethernet,fully
compliantwithIEEE
802.3u
32-bitDSP,
120MIPS
3.5"X3.5"
EV-2
CobraNet
development
platformforusewith
theCM-1andCM-2
modules
CDB-496122-EV2
16
OnedigitalAES3inputstream
(twochannels)oronedigital
AES3outputstream(two
channels).Twoanalogaudio
inputchannels,twoanalog
audiooutputchannels
100BASE-Tx,100
Mbps,fullduplex
Ethernet,fully
compliantwithIEEE
802.3u
32-bitDSP,
120MIPS
8"X7"
CobraCom
Reference
Design
CobraNet
microphoneand
network-powered
loudspeaker
referencedesign
CRD-CobraCom
ReferenceDesign
16
UsingtheCS4961xxseries
providesupto16audio
channelswithaudioDSP
capability
100BASE-Tx,
100Mbps,fullduplex
Ethernet,fully
compliantwithIEEE
802.3uand802.3af
Power-over-Ethernet
32-bitDSP,
120MIPS
5.4"X4"
CobraNet
LEReference
Design
Low-cost,2channel
I/Oend-node
referencedesign
Availabledirect
fromAtteroTech
www.atterotech.
com
2
Stereo1/8"inputandoutput,
stereoRCAinputandoutput,
I2Sdigitalaudiooutputs
100Base-Tx,10
Mbps,fullduplex
Ethernet,fully
compliantwithIEEE
802.3uand802.3af
Power-over-Ethernet
—
5"x3"
CobraNet Transport and
Audio Network Processor ICs
Family
Description
CobraNet
Part Numbers
Audio
Channels
over
Ethernet
Serial Input/Serial Output Ports
Ethernet
Interface
IC
Package
CS1810xx
CS4961xx*
The CS1810xx Family
contains CobraNet
networked digital audio
interface ICs. The
CS4961xx Family
provides digital audio
signal processing along
with the network
interface function.
CS181002
CS496102*
2
Onesynchronous,capableofsupplying
upto2full-duplexchannelsat48
and/orupto96kHzsamplerates.
Supports
100BASE-Tx,
100 Mbps, full
duplex Ethernet,
fully compliant
with IEEE 802.3u.
144 LQFP
CS181012
CS496112*
8
Quadsynchronous,capableofsupplying
upto8full-duplexchannelsat48
and/orupto96kHzsamplerates.
CS181022
CS496122*
16
Quadsynchronous,capableofsupplying
upto16full-duplexchannelsat48kHz,
orupto8channelsat96kHzsamplerates.
*TheCS4961xxseriesincludesa32-bit,120MIPSdigitalsignalprocessorforaudioprocessingofanyorallchannels.
CobraNet Software Tools
Features
DSP Conductor
DSPConductorsoftwareisapowerful,graphicaltoolforrapid,drag-and-dropaudiosignalprocessingfirmwaredevelopmenton
CS4961xx-basedplatforms,suchastheCM-2moduleoranOEM’scustomhardware.Drawinguponacomprehensivelibraryof
DSPfunctions,anOEMcandesigntheaudioprocessingofaproduct,thenlocktheDSPfirmwaredownintotheCS4961xx-based
CobraNetproduct.Theseaudiofunctionscanbecontrolledeitherbytheproduct’suserinterfaceorthroughremoteSNMP
commandsovertheCobraNetEthernetLAN.Further,anyCS4961xxnodecanbere-programmedinreal-timefromaPConthe
network,enablingmulti-purposeproductstoservedifferentaudioprocessingfunctionsfordifferentapplicationsatthepushofa
button.
CobraCAD
CobraCADsoftwareisagraphical,drag-and-dropdesignandverificationtoolformodelinganetworkofCobraNet-enabledgear
andstandardEthernetswitches.Alibraryofcommerciallyavailable,CobraNet-enabledproductsistheplacetostartfordesigning
avirtualCobraNetnetwork,thenmakingsureitwillperformasrequired.CobraCadsoftwareisidealforconsultantsand
integratorspreparingabidforaclientandforinstallersandexpertenduserswhoneedtovisualizethenetworkbeforeorafter
deployment.
CobraNet Discovery
CobraNetDiscoveryisaCobraNetnetworkmaintenanceutilitythatautomaticallydiscoversCobraNetdevicesonthenetwork,
configuresthemandqueriesandreportstheworkingstateofaCobraNetnetworkanditsdevices.Discoveryalsoprovidesa
CobraNetfirmwareupdatefunction.
