2006 California Micro Devices Corp. All rights reserved.
03/20/06
490 N. McCarthy Blvd., Milpitas, CA 95035-5112
●
Tel: 408.263.3214
●
Fax: 408.263.7846
●
www.cmd.com
3
CM3702
Ordering Information
Note 1: Parts are shipped in Tape & Reel form unless otherwise specified.
6, 7
EN_LDO,
EN_CHIP
EN_LDO (pin 6) and EN_CHIP (pin 7) are active-high TTL-level logic inputs to enable the linear
regulator and charge pump according to the following truth table:
8VOUT
The regulated output. An output capacitor may be added to improve noise and load-transient
response. When the LDO regulator is disabled, an internal pull-down with a nominal resistance
of 500 ohms is activated to discharge the VOUT rail to GND
9, 10
CP+, CP-
CP+ (pin 9) and CP- (pin 10) are used to connect the external "flying" capacitor CP to the charge
pump. The charge stored in CP is transferred to the reservoir capacitor CS at the 250kHz inter-
nal clock rate.
PIN DESCRIPTIONS (CONT’D)
EN_CHIP
(Pin 7)
EN_LDO
(Pin 6)
CHARGE PUMP
REGULATOR
1
Enabled
1
0
Enabled
Disabled
0
1
Disabled
0
Disabled
PART NUMBERING INFORMATION
Leads
Package
Standard Finish
Lead-free Finish
Ordering Part
Number1
Part Marking
Ordering Part
Number1
Part Marking
10
MSOP-10
CM3702-50MS
3702 50S
CM3702-50MR
3702 50
