CAT823, CAT824, CAT825
2008 SCILLC. All rights reserved.
3
Doc. No. MD-3027, Rev. C
Characteristics subject to change without notice
ABSOLUTE MAXIMUM RATINGS
(1)
Parameters
Ratings
Units
Supply Voltage
6
V
All other pins
-0.3 to (VCC + 0.3)
V
Input Current, VCC
20
mA
Output Current RST, RST
20
mA
Continuous Power Dissipations (TA = +70C)
SC-70 5-lead (derate 3.1mW/C above +70C)
247
mW
TSOT-23 5-lead (derate 7.1mW/C above +70C)
571
mW
Storage Temperature
-65 to 150
C
Operating Ambient Temperature
-40 to +85
C
Lead Soldering (10 seconds max)
+300
C
ESD Rating: Low Voltage Pins
Human Body Model
2000
V
Machine Model
200
V
RECOMMENDED OPERATING CONDITIONS
Parameter
Range
Units
VCC (TA = 0C to +70C)
1.0 to 5.5
V
VCC (TA = -40C to +85C)
1.2 to 5.5
V
All Other Pins
-0.1 to (VCC + 0.1)
V
Ambient Temperature
-40 to +85
C
Notes:
(1)
Stresses above those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions outside of those listed in the operational sections of this
specification is not implied. Exposure to any absolute maximum rating for extended periods may affect device performance and reliability.
