Catalog Symbol: ATC
Fast-Acting
Ampere Rating: 1 to 40 Amperes
Interrupting Rating: 1,000 Amperes
Agency Approvals: U.L. Recognized, (3-40A)
Guide JFHR2, File E56412
Ordering: Specify packaging and product code
Recommended Bussmann Fuseholders*
Blade-Type
Part
Description
Fuse Size
Wire Size
HHC
Yellow Fuseholder
3-20 Amps
#16 Lead Wire
HHF
Black Fuseholder w/cover
3-20 Amps
#14 Lead Wire
ATC
HHD
Black Fuseholder
3-30 Amps
#12 Lead Wire
HHG
Black Fuseholder w/cover
3-30 Amps
#12 Lead Wire
HHD-C
Cover Only
—
*Also used in Bussmann 1A5600 Fuse Clips (0-20A)
1
0
1
0
1
,0
0
CURRENT IN AMPERES
100
10
1
.1
.01
T
IM
E
IN
S
E
C
O
N
D
S
1
0
1
5
2
0
2
5
3
0
AMPERE
RATING
7
.5
5
4
3
4
0
Time-Current Characteristic Curves–Average Melt
12.5mm
5mm
. m
19.1mm
m
1m
6.67mm
5.25mm
11.7mm
19.3mm
14.6mm
16.7mm
4.13mm
Dimensional Data
.460”
.760”
.207”
.492”
.752”
.263”
.575”
.657”
.163”
SPECIFICATIONS
Product
Body
Voltage
Code
Color
Rating DC
ATC-1
Black
32V
ATC-2
Gray
32V
ATC-3
Violet
32V
ATC-4
Pink
32V
ATC-5
Tan
32V
ATC-7 1/2
Brown
32V
ATC-10
Red
32V
ATC-15
Blue
32V
ATC-20
Yellow
32V
ATC-25
Clear
32V
ATC-30
Green
32V
ATC-40
Amber
32V
PACKAGING CODE
Packaging Code
Description
Blank
5 pieces of fuses packed in a tin
BK
2,000 pieces of fuses packed in a carton
Blade-Type Automotive Fuses
ATC Series, Fast Acting
Visit us on the web at:
www.cooperbussmann.com
OC-2605
3/07
Cooper Electronic
Technologies 2007
Cooper Electronic Technologies
1225 Broken Sound Parkway NW
Suite F
Boca Raton, FL 33487-3533
Tel: 1-561-998-4100
Fax: 1-561-241-6640
Toll Free: 1-888-414-2645
Cooper Bussmann
P.O. Box 14460
St. Louis, MO 63178-4460
Tel: 1-636-394-2877
Fax: 1-800-544-2570
Cooper Electronic Technologies
Cooper (UK) Limited
Burton-on-the-Wolds
Leicestershire LE12 5TH UK
Tel: +44 (0) 1509 882 737
Fax: +44 (0) 1509 882 786
Cooper Electronic Technologies
Avda. Santa Eulalia, 290
08223
Terrassa, (Barcelona), Spain
Tel: +34 937 362 812
+34 937 362 813
Fax: +34 937 362 719
Asia Pacific
Cooper Electronic Technologies
1 Jalan Kilang Timor
#06-01 Pacific Tech Centre
Singapore 159303
Tel: +65 278 6151
Fax: +65 270 4160
North America
Europe
RoHS
2002/95/EC
