181 12/00
MFP
Capacitance tolerance:
± 10 % = K, ± 5 % = J, (± 3,5 % upon request)
Ordering codes and packing units, lead spacing 15 mm
VR
(Vrms,
f
≤ 1 kHz)
CR
Maximum
dimensions
b
× h × l (mm)
Ordering code1)
Packing units (pcs)
Ammo
pack
Reel
Untaped
630 Vdc
(300 Vac)
4,7 nF
5,0
× 10,5 × 18,0
B32682-A6472-+*** 1170
1300
1000
6,8 nF
5,0
× 10,5 × 18,0
B32682-A6682-+*** 1170
1300
1000
10 nF
5,0
× 10,5 × 18,0
B32682-A6103-+*** 1170
1300
1000
15 nF
6,0
× 11,0 × 18,0
B32682-A6153-+***
960
1100
1000
22 nF
7,0
× 12,5 × 18,0
B32682-A6223-+***
830
900
1000
33 nF
8,5
× 14,5 × 18,0
B32682-A6333-+***
680
700
500
47 nF
9,0
× 17,5 × 18,0
B32682-A6473-+***
640
700
500
1000 Vdc
(400 Vac)
3,3 nF
5,0
× 10,5 × 18,0
B32682-A332-+***
1170
1300
1000
4,7 nF
6,0
× 11,0 × 18,0
B32682-A472-+***
960
1100
1000
6,8 nF
7,0
× 12,5 × 18,0
B32682-A682-+***
830
900
1000
10 nF
8,5
× 14,5 × 18,0
B32682-A103-+***
680
700
500
15 nF
9,0
× 17,5 × 18,0
B32682-A153-+***
640
700
500
1250 Vdc
(450 Vac)
2,2 nF
5,0
× 10,5 × 18,0
B32682-A7222-+*** 1170
1300
1000
3,3 nF
6,0
× 11,0 × 18,0
B32682-A7332-+***
960
1100
1000
4,7 nF
7,0
× 12,5 × 18,0
B32682-A7472-+***
830
900
1000
6,8 nF
8,5
× 14,5 × 18,0
B32682-A7682-+***
680
700
500
10 nF
9,0
× 17,5 × 18,0
B32682-A7103-+***
640
700
500
1600 Vdc
(450 Vac)
1,5 nF
5,0
× 10,5 × 18,0
B32682-A1152-+*** 1170
1300
1000
2,2 nF
6,0
× 11,0 × 18,0
B32682-A1222-+***
960
1100
1000
3,3 nF
7,0
× 12,5 × 18,0
B32682-A1332-+***
830
900
1000
4,7 nF
8,5
× 14,5 × 18,0
B32682-A1472-+***
680
700
500
6,8 nF
9,0
× 17,5 × 18,0
B32682-A1682-+***
640
700
500
2000 Vdc
(500 Vac)
0,10 nF 5,0
× 10,5 × 18,0
B32682-A2101-+*** 1170
1300
1000
0,15 nF 5,0
× 10,5 × 18,0
B32682-A2151-+*** 1170
1300
1000
0,22 nF 5,0
× 10,5 × 18,0
B32682-A2221-+*** 1170
1300
1000
0,33 nF 5,0
× 10,5 × 18,0
B32682-A2331-+*** 1170
1300
1000
0,47 nF 5,0
× 10,5 × 18,0
B32682-A2471-+*** 1170
1300
1000
0,68 nF 5,0
× 10,5 × 18,0
B32682-A2681-+*** 1170
1300
1000
1,0 nF
5,0
× 10,5 × 18,0
B32682-A2102-+*** 1170
1300
1000
1,5 nF
6,0
× 11,0 × 18,0
B32682-A2152-+***
960
1100
1000
2,2 nF
7,0
× 12,5 × 18,0
B32682-A2222-+***
830
900
1000
3,3 nF
8,5
× 14,5 × 18,0
B32682-A2332-+***
680
700
500
4,7 nF
9,0
× 17,5 × 18,0
B32682-A2472-+***
640
700
500
1) +
Code letter for capacitance tolerance
*** Code number for packing: Ammo pack = 289, reel = 189
The ordering code for untaped components ends after the tolerance code letter.
For capacitors with 3,2 mm lead length, append code number “3” to the tolerance code, e.g.: B32682-A6472-K3
B32 682
15
