| 型號： | ATMEGA64RZAV-10MU |
| 廠商： | Atmel |
| 文件頁數： | 19/23頁 |
| 文件大小： | 0K |
| 描述： | MCU ATMEGA644/AT86RF230 44-QFN |
| 產品培訓模塊： | MCU Product Line Introduction megaAVR Introduction Introduction to ZigBee Low Power Wireless Networks |
| 標準包裝： | 1 |
| 系列： | ATMEGA |
| 頻率： | 2.4GHz |
| 調制或協議： | 802.15.4 Zigbee |
| 功率 - 輸出： | 3dBm |
| 靈敏度： | -101dBm |
| 電源電壓： | 1.8 V ~ 3.6 V |
| 數據接口： | PCB，表面貼裝 |
| 存儲容量： | 64kB 閃存，2kB EEPROM，4kB RAM |
| 天線連接器： | PCB，表面貼裝 |
| 封裝/外殼： | 44-VFQFN 裸露焊盤 |
| 包裝： | 托盤 |
| 產品目錄頁面： | 553 (CN2011-ZH PDF) |
| 配用： | ATSTK600-TQFP32-ND - STK600 SOCKET/ADAPTER 32-TQFP ATAVRISP2-ND - PROGRAMMER AVR IN SYSTEM ATJTAGICE2-ND - AVR ON-CHIP D-BUG SYSTEM ATSTK500-ND - PROGRAMMER AVR STARTER KIT |
5
2593OS–AVR–02/12
ATmega644
and source capability. As inputs, Port A pins that are externally pulled low will source current if
the pull-up resistors are activated. The Port A pins are tri-stated when a reset condition becomes
active, even if the clock is not running.
Port A also serves the functions of various special features of the ATmega644 as listed on page
73.
2.2.4
Port B (PB7:PB0)
Port B is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The
Port B output buffers have symmetrical drive characteristics with both high sink and source
capability. As inputs, Port B pins that are externally pulled low will source current if the pull-up
resistors are activated. The Port B pins are tri-stated when a reset condition becomes active,
even if the clock is not running.
Port B also serves the functions of various special features of the ATmega644 as listed on page
75.
2.2.5
Port C (PC7:PC0)
Port C is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The
Port C output buffers have symmetrical drive characteristics with both high sink and source
capability. As inputs, Port C pins that are externally pulled low will source current if the pull-up
resistors are activated. The Port C pins are tri-stated when a reset condition becomes active,
even if the clock is not running.
Port C also serves the functions of the JTAG interface, along with special features of the
ATmega644 as listed on page 78.
2.2.6
Port D (PD7:PD0)
Port D is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The
Port D output buffers have symmetrical drive characteristics with both high sink and source
capability. As inputs, Port D pins that are externally pulled low will source current if the pull-up
resistors are activated. The Port D pins are tri-stated when a reset condition becomes active,
even if the clock is not running.
Port D also serves the functions of various special features of the ATmega644 as listed on page
80.
2.2.7
RESET
Reset input. A low level on this pin for longer than the minimum pulse length will generate a
reset, even if the clock is not running. The minimum pulse length is given in ”System and Reset
Characteristics” on page 320. Shorter pulses are not guaranteed to generate a reset.
2.2.8
XTAL1
Input to the inverting Oscillator amplifier and input to the internal clock operating circuit.
2.2.9
XTAL2
Output from the inverting Oscillator amplifier.
