13001 RM (IM) No.6759-1/8
Ver.1.6
12898
Overview
This 2 inch low temperature poly- silicon TFT-LCD module consists of LCD panel and backlight.
This is suitable for digital still camera or for digital video camera.
Features
Diagonal 5.1cm (2.0inch) display size.
557 × 234 = 130,338 dots.
RGB delta color arrangement.
Operating temperature (Panel) is -10 to +60°C. Ambient temperature during storage is -20 to +70°C.
Slim design, light weight and narrow frame. (t=0.7mm glass)
Up / down and right / left inverse function.
Builds in level shifter circuit.
Conform to NTSC, PAL when using recommended IC : LV4127W, LV4135W, LV4137W,
(LV4139W : Under development).
Anti-reflection (AR) coat.
Builds in CCFL backlight unit. (Not contains inverter unit)
Panel power consumption is Typ.100mW at NTSC. Backlight power consumption is 0.6W. (reference)
Display surface luminance is typ 200cd/m2.
Specifications
Item
Dot count (H) × (V)
Effective display dimensions (H) × (V)
Display size (diagonal)
Dot pitch (H) × (V)
Color arrangement
External Dimensions (W) × (H) × (D)
Weight
*Note1: Excluding flexible cable and protrusions.
Specifications
557 × 234
40.98 × 30.77
5.1 (2.0inch)
0.0735 × 0.1315
RGB Delta
TYP 48.3 × 42.1 × 5.5
Approx. 20
Unit
dot
mm
cm
mm
-
mm
g
Remarks
Note1
Low-Temperature Polysilicon
2.0-inch TFT LCD Module
ALP230CCX
Ordering number : ENN6759
LCD Module
