ACS86MS
Metallization Mask Layout
ACS86MS
(2)
(1)
(13)
GND
Y3
Y2
Y1 (3)
A2 (4)
NC
B2 (5)
(12) A4
(11) Y4
NC
A1
B4
B1
(6)
(7)
(8)
(10) B3
(14)
VCC
A3
(9)
Spec Number
518849
Die Characteristics
DIE DIMENSIONS:
88 mils x 88 mils
2.24mm x 2.24mm
METALLIZATION:
Type: AlSiCu
Metal 1 Thickness: 6.75k
(Min), 8.25k
(Max)
Metal 2 Thickness: 9k
(Min), 11k
(Max)
GLASSIVATION:
Type: SiO
2
Thickness: 8k
±
1k
DIE ATTACH:
Material: Silver Glass or JM7000 Polymer after 7/1/95
WORST CASE CURRENT DENSITY:
< 2.0 x 10
5
A/cm
2
BOND PAD SIZE:
> 4.3 mils x 4.3 mils
> 110
μ
m x 110
μ
m
